SA213 Alloy Steel Pipe T5 T9 T11 T12 T22, Carbon Steel Heat Exchanger Tabung
Rincian produk
baja paduan tabung mulus
,seamless alloy steel pipe
Baja paduan kelas T5 T9 T11 T12 T22
pipa baja paduan tabung penukar panas SA213
| Kelas baja | C | Mn | P | S | Ya. | Cr | Mo |
|
| maksimal | maksimal | maksimal | maksimal | maksimal | menit |
|
| T5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.5 | 4.0-6.0 | 0.45-0.65 |
| T9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.0-10.0 | 0.90-1.10 |
| T11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.0-1.50 | 0.44-0.65 |
| T12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
| T21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 2.65-3.35 | 0.80-1.06 |
| T22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
| Kelas baja | Kekuatan tarik | Kekuatan Hasil | Perpanjangan | Kekerasan.Max. |
|
| |
| Min.ksi [Mpa] | Min.ksi [Mpa] | % | Brinell/Vickers | Rockwell |
|
|
|
| T5b | 60[415] | 30[205] | 30 | 179HBW/190HV | 89HRB |
|
|
| T9 | 60[415] | 30[205] | 30 | 179HBW/190HV | 89HRB |
|
|
| T12 | 60[415] | 32[220] | 30 | 163HBW/170HV | 85HRB |
|
|
| T91 | 85[585] | 60[415] | 20 | 250HBW/265HV | 25HRC |
|
|
| T92 | 90[620] | 64[440] | 20 | 250HBW/265HV | 25HRC |
|
|
-
