Super Alloy Steel Pipe Presipitasi Pengerasan Alloy 41 Untuk Komponen Mesin
Rincian produk
tabung baja paduan
,baja paduan tabung mulus
Super Alloy Steel Pipe Precipitation Harding Alloy 41 Untuk Komponen Mesin
Alloy Steel Pipe Alloy 41 precipitation hardening Nickel-Base Superalloy
Alloy41 adalah Superalloy Nickel-Base yang mengeraskan precipitasi, dan memiliki kekuatan tarik dan merangkak yang lebih tinggi dan ketahanan oksidasi yang baik dalam kisaran suhu 650 ~ 950 °C.Karena paduan aluminium, titanium, kandungan molibdenum tinggi, bunga ingot lebih sulit, tetapi bahan setelah deformasi memiliki ductility yang baik,yang membuatnya lebih mudah terbentuk dingin atau dilas dalam keadaan annealedNamun, bagian yang dilas mudah rentan terhadap retakan dan penuaan saat diobati panas.dan cocok untuk pembuatan di bawah 870 °C dengan kekuatan tinggi dan di bawah 980 °C oksidasi suhu tinggi dari komponen mesin penerbangan dan aeroangkasa.
Standar:GB/T14992, GB/T14993
Komposisi kimia dari paduan 41:
| Komposisi kimia (%) | ||||||||||||||
| C | Cr | Tidak | Co. | Mo | Ti | Fe | Zr | Cu | B | Mn | Al | Ya. | P | S |
| 0.06-0.12 | 18.0-20.0 | Margin | 10.0-12.0 | 9.00-10.50 | 3.0-3.50 | ≤ 5 | ≤ 0.07 | ≤ 0.5 | 0.003- 0.010 | ≤ 0.50 | 1.40- 1.80 | ≤ 0.5 | ≤ 0.015 | ≤ 0.015 |
Sifat fisik paduan 41:
ρ:8.27g/cm3
Konduktivitas termal:
| Konduktivitas termal | |||||||||
| Suhu/°C | 100 | 200 | 300 | 400 | 500 | 600 | 700 | 800 | 900 |
| λ/(w/(m°C)) | 8.37 | 10.47 | 12.56 | 15.07 | 17.17 | 20 | 21.35 | 23.45 | 25.96 |
Koefisien ekspansi termal:
| Koefisien ekspansi termal | |||||||||
| Suhu/°C | 20-100 | 20-200 | 20 sampai 300 | 20 sampai 400 | 20 sampai 500 | 20-600 | 20-700 | 20-800 | 20-900 |
| α1/10-6°C-1 | 10.54 | 11.69 | 12.24 | 12.78 | 13.08 | 13.48 | 14.21 | 14.97 | 15.91 |
Properti Mekanis Paduan 41:
| Sifat Mekanis | ||||||
| Bentuk | Pengolahan Panas | Kekuatan tarik σb/MPa | Kekuatan Hasil σp0.2/Mpa | Perpanjangan setelah patah tulang σ5 /% | Tingkat penyusutan Ψ/% | Kekerasan HBS |
| Unit cincin/bar | larutan padat+penuaan | ≥835 | ≥ 620 | ≥ 12 | ≥ 15 | ≥ 283 |
| pengikat | larutan padat+penuaan | ≥1070 | - | ≥ 8 | ≥ 10 | - |
-
