Pipa tanpa jahitan dari Baja Alloy Incoloy 800
Properti Dasar
Tempat Asal:
Zhejiang China
Nama merek:
TORICH
Sertifikasi:
ISO 9001
Nomor Model:
GB / T 30059
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
USD 1200-1500 Per Ton
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
500 ton per bulan
Ringkasan Produk
Deskripsi produk: Untuk penukar panas GB/T 30059 Incoloy 800 Inconel 600 Tabung paduan tahan korosi tanpa jahitan China Inconel Steel Tube produsen, memilih kualitas tinggi Inconel Steel Pipe, Incoloy Steel Tube, Black Carbon Steel Welded Pipe, Oval Steel Tube dll Jangkauan ukuran: OD: 6-219mmWT: 0...
Rincian produk
Menyoroti:
inconel 600 tube
,inconel 601 tube
OD:
6-219mm
WT:
0,5-10mm
Length:
2-12m
Material:
Incoloy 800, Incoloy 825, Inconel 600 Dll
Deskripsi Produk
Deskripsi produk:
Untuk penukar panas GB/T 30059 Incoloy 800 Inconel 600 Tabung paduan tahan korosi tanpa jahitan
China Inconel Steel Tube produsen, memilih kualitas tinggi Inconel Steel Pipe, Incoloy Steel Tube, Black Carbon Steel Welded Pipe, Oval Steel Tube dll
Jangkauan ukuran:
OD: 6-219mm
WT: 0,5-10mm
Panjang: 2000-12000mm
Ukuran biasa kami: 26.7x2.87mm, 6.35x1.65mm, 25x2mm dll
Kelas baja/bahan baja:
| Kelas baja | Kelas Baja ASTM | C | Cr | Tidak | Fe | Mo | Cu | Al | Ti | Nb | Co. | Ya. | Mn | P | S |
| NS1101 |
N08800 (Incoloy 800) |
≤ 0.010 | 19.0-23.0 | 30.0-35.0 | Sisanya | - | ≤ 0.75 | 0.15-0.60 | 0.15-0.60 | - | - | ≤ 1.00 | ≤ 1.50 | ≤ 0.030 | ≤ 0.015 |
| NS1102 | N08810 (Incoloy 800H) |
0.05-0.10 | 19.0-23.0 | 30.0-35.0 | Sisanya | - | ≤ 0.75 | 0.15-0.60 | 0.15-0.60 | - | - | ≤ 1.00 | ≤ 1.50 | ≤ 0.030 | ≤ 0.015 |
| NS1103 | - | ≤ 0.030 | 24.0-26.5 | 34.0-37.0 | Sisanya | - | - | 0.15-0.45 | 0.15-0.60 | - | - | 0.30-0.70 | 0.50-1.50 | ≤ 0.030 | ≤ 0.030 |
| NS1401 | - | ≤ 0.030 | 25.0-27.0 | 34.0-37.0 | Sisanya | 2.0-3.0 | 3.0-4.0 | - | 0.40-0.90 | - | - | ≤ 0.70 | ≤ 1.00 | ≤ 0.030 | ≤ 0.030 |
| NS1402 | N08825 (Incoloy 825) |
≤ 0.05 | 19.0-23.5 | 38.0-46.0 | ≥ 22.0 | 2.5-3.5 | 1.5-3.0 | ≤ 0.20 | 0.60-1.20 | - | - | ≤ 0.50 | ≤ 1.00 | ≤ 0.030 | ≤ 0.015 |
| NS3102 | N06600 (Inconel 600) |
≤ 0.15 | 14.0-17.0 | Sisanya | 6.0-10.0 | - | ≤ 0.50 | - | - | - | - | ≤ 0.50 | ≤ 1.00 | ≤ 0.030 | ≤ 0.015 |
| NS3105 | N06690 (Inconel 690) |
≤ 0.05 | 27.0-31.0 | Sisanya | 7.0-11.0 | - | ≤ 0.50 | - | - | - | - | ≤ 0.50 | ≤ 0.50 | ≤ 0.030 | ≤ 0.015 |
| NS3306 | N06625 (Inconel 625) |
≤ 0.10 | 20.0-23.0 | Sisanya | ≤ 5.0 | 8.0-10.0 | - | ≤ 0.40 | ≤ 0.40 | 3.15-4.15 | ≤ 1.00 | ≤ 0.50 | ≤ 0.50 | ≤ 0.015 | ≤ 0.015 |
Sifat Mekanis:
| Kelas baja | Kelas Baja ASTM | Sifat Mekanis | ||
|
Kekuatan tarik Rm/MPa |
Kekuatan Hasil RP0.2/MPa |
Perpanjangan A/% |
||
| ≥ | ||||
| NS1101 | N08800 (Incoloy 800) |
517 | 207 | 30 |
| NS1102 | N08810 (Incoloy 800H) |
448 | 172 | 30 |
| NS1103 | - | 515 | 205 | 30 |
| NS1404 | - | 540 | 215 | 35 |
| NS1402 | N08825 (Incoloy 825) |
586 | 241 | 30 |
| NS3102 | N06600 (Inconel 600) |
552 | 241 | 30 |
| NS3105 | N06690 (Inconel 690) |
586 | 241 | 30 |
| NS3306 | N06625 (Inconel 625) |
690 | 276 | 30 |
Kondisi pengiriman:
Diiris dan ditumis, diiris terang, ditarik dingin atau digulung dingin
Karakteristik pipa berlapis:
Kekuatan tinggi
Mudah dibentuk mesin
Tahan korosi
Kualitas stabil
Kerontokan yang halus
TORICH Jaminan Kualitas
Proses Produksi:
Pengolahan dan pemurnian bahan bakar
Pemasok dingin tanpa jahitan atau digulung dingin tanpa jahitan
Bahan baku baja:
Garis produksi:
Uji arus eddy dan uji ultrasonik:
Inspeksi kualitas di laboratorium:
Kemasan:
