DIN 2440 2441 & EN10255 S195T Pengelasan / Threading Tabung Baja Tanpa Paduan
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
GB/T 19001-2008 , ABS , CCS , DNV , GL
Nomor Model:
DIN 2440 2441 & EN10255
Properti Perdagangan
Jumlah Pesanan Minimum:
5MT
Harga:
USD600-900 per ton
Kemampuan Penyediaan:
7000MT / Bulan
Ringkasan Produk
DIN 2440 2441&EN10255 S195T Tabung Baja Tidak Diasosiasi, Pipa Baja Struktural DIN 2440 2441&EN10255 Tabung baja tahan karat,cocok untuk pengelasan dan threading Aplikasi: untuk konversi bahan bakar serta untuk aplikasi lain Rentang ukuran: O.D.:6-350mm W.T.:1-30mm L:di bawah 12000mm Pembuatan...
Rincian produk
Menyoroti:
cold formed steel tube
,structural steel square tubing
Dimension::
6-168mm * 1-30mm * di bawah12000mm
Application::
Untuk konsumsi bahan bakar serta untuk aplikasi lain
Product Name::
pipa baja struktural
Grade::
S195T
Deskripsi Produk
DIN 2440 2441&EN10255 S195T Tabung Baja Tidak Diasosiasi, Pipa Baja Struktural
DIN 2440 2441&EN10255 Tabung baja tahan karat,cocok untuk pengelasan dan threading
Aplikasi: untuk konversi bahan bakar serta untuk aplikasi lain
Rentang ukuran: O.D.:6-350mm W.T.:1-30mm L:di bawah 12000mm
Pembuatan:Tabung-tabung ini diproduksi dengan proses pengelasan tanpa jahitan atau panjang.
Komposisi kimia:
| Besi kelas | C | Mn | P | S | |
| Nama baja | Nomor baja | maksimal | maksimal | maksimal | maksimal |
| S 195T | 1.0026 | 0.2 | 1.4 | 0.035 | 0.030 |
Catatan: Kelas baja khusus juga tersedia, sesuai permintaan pelanggan.
Sifat mekanik:
| Kelas baja | Kekuatan hasil atas | Tensile Kekuatan Rm | Perpanjangan | ||||
| Nama baja | Nomor baja | RH min untuk Ketebalan dinding | |||||
| Min.% | |||||||
| MPa | |||||||
| S 195T | 1.0026 | 195 | 320-520 | 20 | |||
Dimensi, diameter dan massa per unit tength:
| Spesifikasi di luar diamerter D (mm) | Benang Ukuran R | Di luar diameter | H Berat seri | M Seri menengah | |||||
| Dinding Ketebalan T (mm) | Massa per unit Panjang tabung kosong | Dinding Ketebalan T (mm) | Massa per unit Panjang tabung kosong | ||||||
| Maksimal (mm) | Min (mm) | ||||||||
| Akhir yang sederhana (kg/m) | Dengan soket (kg/m) | Akhir yang sederhana (kg/m) | Benang dan dengan soket (kg/m) | ||||||
| 10.2 | 1/8 | 10.6 | 9.8 | 2.6 | 0.487 | 0.490 | 2.0 | 0.404 | 0.407 |
| 13.5 | 1/4 | 14.0 | 13.2 | 2.9 | 0.765 | 0.769 | 2.3 | 0.641 | 0.645 |
| 17.2 | 3/8 | 17.5 | 16.7 | 2.9 | 1.02 | 1.03 | 2.3 | 0.839 | 0.845 |
| 21.3 | 1/2 | 21.8 | 21.0 | 3.2 | 1.44 | 1.45 | 2.6 | 1.21 | 1.22 |
| 26.9 | 3/4 | 27.3 | 26.5 | 3.2 | 1.87 | 1.88 | 2.6 | 1.56 | 1.57 |
| 33.7 | 1 | 34.2 | 33.3 | 4.0 | 2.93 | 2.95 | 3.2 | 2.41 | 2.43 |
| 42.4 | 11/4 | 42.9 | 42.0 | 4.0 | 3.79 | 3.82 | 3.2 | 3.10 | 3.13 |
| 48.3 | Pembagian, 11/2 | 48.8 | 47.9 | 4.0 | 4.37 | 4.41 | 3.2 | 3.56 | 3.60 |
| 60.3 | 2 | 60.8 | 59.7 | 4.5 | 6.19 | 6.26 | 3.6 | 5.03 | 5.10 |
| 76.1 | 21/2 | 76.6 | 75.3 | 4.5 | 7.93 | 8.05 | 3.6 | 6.42 | 6.54 |
| 88.9 | 3 | 89.5 | 88.0 | 5.0 | 10.3 | 10.5 | 4.0 | 8.36 | 8.53 |
| 114.3 | 4 | 115.0 | 113.1 | 5.4 | 14.5 | 14.8 | 4.5 | 12.2 | 12.5 |
| 139.7 | 5 | 140.8 | 138.5 | 5.4 | 17.9 | 18.4 | 5.0 | 16.6 | 17.1 |
| 165.1 | 6 | 166.5 | 163.9 | 5.4 | 21.3 | 21.9 | 5.0 | 19.8 | 20.4 |
