Kustom 5.8m / 6m 10 # 20 # 45 # 12 CrMo Tabung Baja Mulus GB6479
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO14001
Nomor Model:
GB6479
Properti Perdagangan
Jumlah Pesanan Minimum:
3tons
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
50000tons/tahun
Ringkasan Produk
GB6479 Tabung baja tanpa jahitan untuk peralatan pupuk kimia tekanan tinggi Tabung baja tanpa jahitan Kelas baja/bahan baja:10#, 20#, 45#, 12CrMo Standar pipa baja:GB6479 ukuran: OD:10.00 ¢ 700mm WT:1.00 ¢ 60mm Panjang: 5,8m, 6m, atau sesuai kebutuhan. Proses Produksi: Bahan baku ↓ Inspeksi yang ...
Rincian produk
Menyoroti:
stainless steel presisi tubing
,Seamless Carbon Steel tube
Product Name:
GB6479 Tabung Baja Mulus
Keyword:
tabung baja mulus
Type:
Tabung Baja Seamless
Surface:
diminyaki
Material:
10 #, 20 #, 45 #, paduan Cr-Mo, 16Mn, SAE1010, SAE1020,
Usage:
Pipa minyak
Shape:
Bulat
Length:
2-12 m
OD:
10-110mm
WT:
1-8mm
Deskripsi Produk
GB6479 Tabung baja tanpa jahitan untuk peralatan pupuk kimia tekanan tinggi
Tabung baja tanpa jahitan
Kelas baja/bahan baja:10#, 20#, 45#, 12CrMo
Standar pipa baja:GB6479
ukuran:
OD:10.00 ¢ 700mm
WT:1.00 ¢ 60mm
Panjang: 5,8m, 6m, atau sesuai kebutuhan.
Proses Produksi:
Bahan baku
↓
Inspeksi yang datang
↓
Penyimpanan → Pemotongan → Pemukul → PemotonganPHOSPHORI CLEAN
↓
PEMUTUSAN ◄ PEMUTUSAN ◄ PENGURUSAN ◄ PENGURUSAN ◄ PEMUTUSAN ◄ PEMUTUSAN ◄ PEMUTUSAN ◄ PEMUTUSAN
↓
INSPEKSI FINAL→PEMBUNJUKAN→PENGALANGAN
| Standar | Kelas | Komposisi kimia (%) | |||||||
| C | Mn | Ya. | Mo | V | W | Nb | P.S | ||
| GB6479 | 20 | 0.17-0.24 | 0.35-0.65 | 0.17-0.37 | / | / | / | / | <= 0.03 |
| 16Mn | 0.12-0.20 | 1.20-1.60 | 0.20-0.60 | / | / | / | / | <= 0.03 | |
| 10 | 0.07-0.14 | 0.35-0.65 | 0.17-0.37 | / | / | / | / | <= 0.03 | |
| 10Bulan | 0.07-0.13 | 0.50-0.80 | 0.50-0.80 | / | / | / | / | <= 0.03 | |
| Sifat Mekanis | Kekuatan tarik ((Mpa) | Kekuatan Hasil (Mpa) | Perpanjangan (%) | ||||||
| 20 | 410-550 | >=245 | >=24 | ||||||
| 16Mn | 490-670 | >=320 | >=21 | ||||||
| 10 | 335-490 | >=205 | >=24 | ||||||
| 10Bulan | 470-670 | >=295 | >=19 | ||||||
Aplikasi:
1)Petroleum, perusahaan kimia, superheater boiler, penukar panas
2)Selad cairan transmisi tahan suhu tinggi di pembangkit listrik
3)Kapal dengan pipa tekanan
