GB / T3093 10A 20A Q345A Tekanan Tinggi Tabung Baja Mulus Untuk Mesin Diesel
Rincian produk
Pipa baja mulus
,Seamless Carbon Steel tube
GB/T3093 10A 20A Q345A Tabung baja tanpa jahitan bertekanan tinggi untuk mesin diesel
Jika Anda telah mengejar kualitas tertinggi, maka tidak melihat lebih jauh dari ini.Pipa baja tanpa jahitanbergairah untuk memberikan apa-apa kurang dari keunggulan.Kami menempatkan pipa baja tanpa jahitan di bawah pemeriksaan kualitas yang intensif diuji terhadap berbagai parameter untuk memastikan bahwa kualitas menjanjikan yang kami tawarkan sesuai dengan standar kualitas internasional.
Kelas baja/bahan baja/nomor baja:
10A 20A Q345A
| Kelas | Komponen Kimia (Fraksi Kualitas) /% | |||||||
| C | Ya. | Mn | P | S | Cr | Tidak | Cu | |
| Tidak lebih dari | ||||||||
| 10A | 0.07 ~ 0.13 | 0.17 ~ 0.37 | 0.35 ~ 0.65 | 0.030 | 0.030 | 0.15 | 0.30 | 0.20 |
| 20A | 0.17 ~ 0.23 | 0.17 ~ 0.37 | 0.35 ~ 0.65 | 0.030 | 0.030 | 0.25 | 0.30 | 0.20 |
| Q345A | ≤ 0.20 | ≤ 0.55 | 1.00 ~ 1.60 | 0.030 | 0.030 | 0.30 | 0.30 | 0.20 |
Jangkauan ukuran:
OD: 6-530mm
WT:0.5-38.1mm
Panjangnya:1.5-6m, sesuai kebutuhan pelanggan
Sifat Mekanis:
| Kelas | Kekuatan perpanjangan MPa | Titik Yield MPa | Perpanjangan % |
| Tidak lebih dari | |||
| 10A | 335 ~ 470 | 205 | 30 |
| 20A | 390 ~ 540 | 245 | 25 |
| Q345A | 470 ~ 630 | 345 | 22 |
Proses pembuatan:
Ditarik dengan dingin
Ketentuan Pengiriman:
Kondisi Pengolahan Panas
Pemeriksaan di kapal kerja:
Pengukuran Ukuran
Pemeriksaan NDT: dengan uji eddy current, uji ultrasonik
Tes mekanik.
APernyataan:
Untuk Mesin Diesel
-
