Baja Karbon Hot Rolled Tube Baja Mulus GB / T 8163 12M Panjang Maks
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
TS16949 ISO14001 ISO9001
Nomor Model:
GB / T8163
Properti Perdagangan
Jumlah Pesanan Minimum:
10TONS
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
60000tons per tahun
Ringkasan Produk
TORICH 1010 1020 10# 20# Baja Karbon Hot digulung Seamless Steel Pipe Tube untuk Layanan Cairan GB / T 8163 Kelas baja/bahan baja: Sifat Mekanis ((panjang): Kelas baja Kekuatan tarik MPa Kekuatan hasil MPa Elongasi % s≤16 s> 16 Tidak kurang dari 10 335-475 205 195 24 10 410-550 245 235 20 Q295 430...
Rincian produk
Menyoroti:
stainless steel presisi tubing
,Seamless Carbon Steel tube
Material:
1020 1010 10#20#
O.D.:
76-600mm
W.T.:
6-50
Length:
maksimal 12m
End:
Polos
Surface:
Tidak ada
Deskripsi Produk
TORICH 1010 1020 10# 20# Baja Karbon Hot digulung Seamless Steel Pipe Tube untuk Layanan Cairan GB / T 8163
Kelas baja/bahan baja:
Sifat Mekanis ((panjang):
| Kelas baja | Kekuatan tarik MPa | Kekuatan hasil MPa | Elongasi % | |
| s≤16 | s> 16 | |||
| Tidak kurang dari | ||||
| 10 | 335-475 | 205 | 195 | 24 |
| 10 | 410-550 | 245 | 235 | 20 |
| Q295 | 430-610 | 295 | 285 | 22 |
| Q345 | 490-665 | 325 | 315 | 21 |
Tes
| Artikel | Titik uji |
| 1 | Sifat mekanik |
| 2 | Perpanjangan |
| 3 | Dampak |
| 4 | Pengujian Permukaan |
| 5 | Pengujian dengan Flaring |
| 6 | Cold Bend |
| 7 | Hidraulik |
| 8 | U.T. |
| 9 | E.T. |
| 10 | MFL |
Kondisi pengiriman:
Hot rolling, annealing, normalisasi
Jangkauan ukuran:
OD: 76-660mm
WT:6-60mm
Panjang: maksimal 12000mm
Ukuran produksi biasa kami: 73x3.5mm, 114x6mm, 203x10mm dll
Karakteristik tabung baja tanpa jahitan:
Kualitas Permukaan yang Baik
Toleransi OD dan ID yang baik dikontrol sesuai dengan standar teknis
Kualitas stabil
100% Uji arus Eddy
TORICH Jaminan Kualitas
Proses Produksi:
Pengolahan panas atau pengolahan panas
Gulung panas tanpa jahitan
