GB / T 28413 SA178 Pipa Baja Karbon Dilas Untuk Penukar Boiler / Panas
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
TS16949 ISO9001 ISO 14001
Nomor Model:
GB / T 28413
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
800-1500 USD/Ton
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
50000 Ton / Tahun
Ringkasan Produk
GB/T 28413 SA178 Pipa baja karbon las Untuk boiler dan penukar panas Standar Teknis Cina GB/T 28413 Pipa Baja Karbon Las Untuk Boiler dan Penukar Panas Kelas baja/bahan baja/nomor baja: 10# 20# Q245R Q345R Q370R Jangkauan ukuran: OD: 6-127mm Min WT:0.9-9.1mm Panjang: 4-12m, sesuai kebutuhan ...
Rincian produk
Menyoroti:
pipa baja dilas
,pengelasan pipa baja
Standard:
GB / T 28413
Grade:
10 # 20 # Q245R Q345R Q370R
Technique:
Lasan
Section Shape:
Rounc
Certification:
TS16949 ISO9001 ISO 14001
Alloy Or Not:
Bebas-alloy
Secondary Or Not:
Non-sekunder
Special Pipe:
pipa baja dilas
Deskripsi Produk
GB/T 28413 SA178 Pipa baja karbon las Untuk boiler dan penukar panas
Standar Teknis Cina GB/T 28413 Pipa Baja Karbon Las Untuk Boiler dan Penukar Panas
Kelas baja/bahan baja/nomor baja:
10# 20# Q245R Q345R Q370R
Jangkauan ukuran:
OD: 6-127mm
Min WT:0.9-9.1mm
Panjang: 4-12m, sesuai kebutuhan pelanggan
Sifat Mekanis:
| Kelas | Kekuatan hasil yang lebih rendah Rel/N/mm2 Tidak kurang dari | Kekuatan tarik R. /N/mm2 Tidak kurang dari | Ekstensibilitas setelah patah tulang A/% Tidak kurang dari | ||||
| T≤16 | 16| 36 | T≤16 | 16 | 36 | | ||
| 10 | 205 | 335-475 | 28 | ||||
| 20 | 245 | 410-550 | 24 | ||||
| Q245R | 245 | 235 | 225 | 400-520 | 25 | ||
| Q345R | 345 | 325 | 315 | 510-640 | 500-630 | 490-620 | 21 |
| Q370R | 370 | 360 | 340 | 530-630 | 520-620 | 20 | |
Proses pembuatan:
HFW High frequency welded
EFW (SAW SMAW GMAW FCAW ESW)
Ketentuan Pengiriman:
Berwarna hitam
Seam online normalisasi.
Pemeriksaan di kapal kerja:
Pengukuran Ukuran
Pemeriksaan NDT: dengan uji eddy current, uji ultrasonik
Tes mekanik.
APernyataan:
Untuk Boiler dan penukar panas
