GB / T 3093 TORICH Tabung Baja Seamless Tekanan Tinggi untuk Mesin Diesel
Rincian produk
stainless steel presisi tubing
,Seamless Carbon Steel tube
GB/T 3093 TORICH Tabung baja tanpa jahitan bertekanan tinggi untuk mesin diesel
Spesifikasi:
Bahan:10A 20A Q345A
Jangkauan Ukuran:OD:4-1200mm
WT:0.3-200mm
Panjang Umum:1.5- 6m
Toleransi:
Menurut tabel berikut atau permintaan pelanggan.
Karakteristik:Keperluan Teknis
Komponen kimia
| Nama
| Kelas | Komponen kimia(pecahan massa)% | |||||||
| C | Ya. | Mn | P | S | Cr | Tidak | Cu | ||
| Maksimal | |||||||||
| U20103 | 10A | 0.07-0.13 | 0.17-0.37 | 0.35-0.65 | 0.03 | 0.03 | 0.15 | 0.30 | 0.20 |
| U20203 | 20A | 0.17-0.23 | 0.17-0.37 | 0.35-0.65 | 0.03 | 0.03 | 0.25 | 0.30 | 0.20 |
| L03451 | Q345A | 0.20Max | 0.55Max | 1.00-1.60 | 0.03 | 0.30 | 0.30 | 0.30 | 0.20 |
Sifat Mekanis:
| Kelas | Kekuatan tarik /Mpa | Kekuatan yield/Mpa | Perpanjangan/% |
| Maksimal | |||
| 10A | 335-470 | 205 | 30 |
| 20A | 390-540 | 245 | 25 |
| Q345A | 470-630 | 345 | 22 |
Metode Produksi:Ditarik dingin
Kondisi teknis pengiriman:Ditarik dingin + Pengolahan panas
Digunakan secara luas di bidang/Aplikasi:Mesin diesel
Gambar produk:
KONTROL KUALITAS
1~ Pemeriksaan bahan baku yang masuk
2~ Pengelompokan bahan baku untuk menghindari campuran kelas baja
3~ Pemanasan dan Pencakar ujung untuk menggambar dingin
4~ Menggambar dingin dan penggulung dingin, pemeriksaan di jalur
5~ Pengolahan panas, +A, +SRA, +LC, +N, Q+T
6~ Perataan-Potong ke panjang yang ditentukan-Pengukuran selesai
7~ Pengujian mekanik di laboratorium sendiri dengan kekuatan tarik, kekuatan hasil, elongasi, kekerasan, dampak, struktur mikro dll
8~ Pengemasan dan Pengepakan.
100% dari tabung baja kami diperiksa dimensi
100% tabung baja kami diperiksa secara visual untuk memastikan mereka memiliki kondisi permukaan yang sempurna dan tidak ada cacat permukaan.
Uji arus pusaran 100% dan uji ultrasonik untuk menghilangkan cacat longitudinal dan transversal.
-
