Stainless Steel Tabung U Bend 6mm Dilas Feritik Pipa Baja GB / T 30065
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO 9001 ISO14001 TS16949
Nomor Model:
GB / T 30065
Properti Perdagangan
Jumlah Pesanan Minimum:
1 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 Ton per Tahun
Ringkasan Produk
Deskripsi produk: Stainless Steel U Bend Tube 6mm Pipa Baja Las GB/T 30065 Kelas baja/bahan baja: Kelas baja Komposisi Kimia, % C Mn P S Ya. Tidak Cr Mo Cu N 019Cr22CuNbTi ≤ 0.025 ≤ 1.00 ≤ 0.030 ≤ 0.015 ≤ 1.00 ≤ 0.60 20.00-23.00 - 0.30-0.80 ≤ 0.025 019Cr22Mo ≤ 0.025 ≤ 1.00 ≤ 0.030 ≤ 0.020 ≤ 1.00 ≤ 0...
Rincian produk
Menyoroti:
stainless tube steel
,diameter besar tabung baja stainless
Characteristic:
Tabung Bend U Stainless Feritik Dilas
Material:
019Cr2CuNbTi, 019Cr22Mo, 019Cr22Mo2 dll
Production Method:
uto-welding dari Cold Rolled Steel Strip
Package:
Dalam bundel atau sesuai permintaan
End Protector:
Polos
Length:
Sesuai dengan kebutuhan pelanggan
Type:
Tabung Stainless
MTC:
EN10204.3.1
Deskripsi Produk
Deskripsi produk:
Stainless Steel U Bend Tube 6mm Pipa Baja Las GB/T 30065
Kelas baja/bahan baja:
| Kelas baja | Komposisi Kimia, % | |||||||||
| C | Mn | P | S | Ya. | Tidak | Cr | Mo | Cu | N | |
| 019Cr22CuNbTi | ≤ 0.025 | ≤ 1.00 | ≤ 0.030 | ≤ 0.015 | ≤ 1.00 | ≤ 0.60 | 20.00-23.00 | - | 0.30-0.80 | ≤ 0.025 |
| 019Cr22Mo | ≤ 0.025 | ≤ 1.00 | ≤ 0.030 | ≤ 0.020 | ≤ 1.00 | ≤ 0.60 | 21.00-24.00 | 0.70-1.50 | - | ≤ 0.025 |
| 019Cr22Mo2 | ≤ 0.025 | ≤ 1.00 | ≤ 0.030 | ≤ 0.020 | ≤ 1.00 | ≤ 0.60 | 24.00-24.00 | 1.50-2.50 | - | ≤ 0.025 |
| 019Cr24Mo2NbTi | ≤ 0.025 | ≤ 0.40 | ≤ 0.030 | ≤ 0.020 | ≤ 0.60 | ≤ 0.60 | 23.00-25.00 | 2.00-3.00 | ≤ 0.60 | ≤ 0.025 |
| 008Cr27Mo | ≤ 0.010 | ≤ 0.40 | ≤ 0.020 | ≤ 0.020 | ≤ 0.40 | ≤ 0.50 | 25.00-27.50 | 0.75-1.50 | ≤ 0.20 | ≤ 0.015 |
Sifat Mekanis:
| Kelas baja | Kekuatan tarik Rm MPa | Kekuatan Pembuatan Rp0.2 MPa | Perpanjangan A50 mm % |
| ≥ | |||
| 019Cr22CuNbTi | 390 | 205 | 22 |
| 019Cr22Mo | 410 | 245 | 25 |
| 019Cr22Mo2 | 410 | 245 | 25 |
| 019Cr24Mo2NbTi | 410 | 245 | 25 |
| 008Cr27Mo | 450 | 275 | 20 |
Kondisi pengiriman:
Dipanaskan dan Digoreng
Jangkauan ukuran:
OD: 12-32mm
WT: 0,5-2,5mm
Panjang: sesuai kebutuhan pelanggan
Ukuran biasa kami: 12.7x0.889mm, 19.05x1.65mm, 19.05x2.11mm dll
Karakteristik pipa berlapis:
Kekuatan tinggi
Bisa membungkuk menjadi tabung U
Tahan korosi
Kualitas stabil
Kerontokan yang halus
TORICH Jaminan Kualitas
Proses Produksi:
Pengelasan otomatis dari strip baja yang digulung dingin + Pengolahan panas dari annealed dan pickled
Bending dengan Cold Bending
Bahan baku baja:
Garis produksi:
Uji arus eddy dan uji ultrasonik:
Inspeksi kualitas di laboratorium:
