GCr15 100Cr6 Tabung Baja Mulus, Tabung Baja Gulungan Dingin Presisi Untuk Suku Cadang Mobil
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 ISO14001 TS16949
Nomor Model:
ISO683-17
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 Ton per Tahun
Ringkasan Produk
Deskripsi produk: ISO 683-17 Cold Drawn Seamless Bearing Steel Tube GCr15 100Cr6 Kelas baja/bahan baja: Kelas baja pecahan massa % C Ya. Mn P S Cr Mo GCr15 0.95-1.05 0.15-0.35 0.20-0.40 ≤ 0.027 ≤ 0.020 1.30-1.65 ≤ 0.10 100Cr6 0.93-1.05 0.15-0.35 0.25-0.45 ≤ 0.025 ≤ 0.015 1.35-1.60 ≤ 0.10 100CrMnSi6...
Rincian produk
Menyoroti:
Pipa baja mulus
,stainless steel presisi tubing
Characteristic:
Tabung Baja Bantalan Mulus
Material:
GCr15, 100Cr6, 20Cr3 dll
Production Method:
Cold Drawn / Cold Rolled
Package:
Dalam bundel atau sesuai permintaan
End Protector:
Polos / Miring
Length:
2-12m
Type:
Tabung Baja Bantalan
MTC:
EN10204.3.1
Deskripsi Produk
Deskripsi produk:
ISO 683-17 Cold Drawn Seamless Bearing Steel Tube GCr15 100Cr6
Kelas baja/bahan baja:
| Kelas baja | pecahan massa % | ||||||
| C | Ya. | Mn | P | S | Cr | Mo | |
| GCr15 | 0.95-1.05 | 0.15-0.35 | 0.20-0.40 | ≤ 0.027 | ≤ 0.020 | 1.30-1.65 | ≤ 0.10 |
| 100Cr6 | 0.93-1.05 | 0.15-0.35 | 0.25-0.45 | ≤ 0.025 | ≤ 0.015 | 1.35-1.60 | ≤ 0.10 |
| 100CrMnSi6-4 | 0.93-1.05 | 0.45-0.75 | 1.00-1.20 | ≤ 0.025 | ≤ 0.015 | 1.40-1.65 | ≤ 0.10 |
| 100CrMnSi6-6 | 0.93-1.05 | 0.45-0.75 | 1.40-1.70 | ≤ 0.025 | ≤ 0.015 | 1.40-1.65 | ≤ 0.10 |
| 100CrMo7 | 0.93-1.05 | 0.15-0.45 | 0.25-0.45 | ≤ 0.025 | ≤ 0.015 | 1.65-1.95 | 0.15-0.30 |
Kondisi pengiriman:+C, +LC, +SR, +A, +N
Jangkauan ukuran:
OD: 10-260mm
WT: 2-30mm
Panjang: 2-12m
Ukuran biasa kami: 29.4x5.6mm, 36.9x7.73mm, 62.9x7.3mm dll
Karakteristik tabung baja bantalan:
Kekuatan tinggi
Tinggi presisi
Kualitas Permukaan yang Baik
Kualitas stabil
Kerontokan yang halus
TORICH Jaminan Kualitas
Proses Produksi:
Pengolahan panas
Tabung Baja Produksi 100Cr6:
Garis produksi:
Uji arus eddy dan uji ultrasonik:
