4.76 X0.5 Tabung Baja Karbon Rendah Dilas SAE J 526 UNS G10080 dan UNS G10100
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 TS16949 ISO14001
Nomor Model:
SAE JS 526 B
Properti Perdagangan
Jumlah Pesanan Minimum:
3 ton
Harga:
2USD-3USD/kg
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
2000 TON/TAHUN
Ringkasan Produk
4.76 X0.5 Tubing baja rendah karbon las SAE J 526 UNS G10080 dan UNS G10100 Tabung baja ber dinding tunggal las listrik digunakan digunakan untuk industri mobil dan kulkas. Sebagian besar fitur produk sangat mirip dengan tabung dinding ganda. Spesifikasi teknis harus sesuai dengan JAM101-94 dan SAE ...
Rincian produk
Menyoroti:
pipa baja dilas
,Listrik perlawanan dilas tabung baja
Material:
1008 atau 1010
Standard:
SAE J 526
OD:
4-10mm
WT:
0.7mm
Length:
Panjang lurus dan kumparan
Section Shape:
Bulat
Secondary Or Not:
Non-sekunder
Technique:
ERW
Thickness:
0,4 - 50 mm
Deskripsi Produk
4.76 X0.5 Tubing baja rendah karbon las SAE J 526 UNS G10080 dan UNS G10100
Tabung baja ber dinding tunggal las listrik digunakan digunakan untuk industri mobil dan kulkas.
Sebagian besar fitur produk sangat mirip dengan tabung dinding ganda.
Spesifikasi teknis harus sesuai dengan JAM101-94 dan SAE JS526 b untuk penggunaan mobil.
Dimensi dan spesifikasi
| O.D. | Ketebalan ((mm) | Berat ((g/m) | Tekanan jaminan ((kg/cm3) |
| 4.00 | 0.50 | 43.21 | 250 |
| 4.20 | 0.50/0.70 | 45.68/60.50 | 250 |
| 4.76 | 0.70 | 70.18 | 250 |
| 6.00 | 0.70 | 91.61 | 250 |
| 6.35 | 0.70 | 97.66 | 250 |
| 8.00 | 0.7/1.0 | 126.18/172.85 | 200 |
| 9.53 | 0.7/1.0 | 152.63/210.63 | 200 |
| 10.0 | 0.7/1.0 | 160.75/222.24 | 200 |
Komposisi Kimia
C ≤ 0,12%
Mn ≤ 0,50%
P≤ 0,04%
S≤ 0,045%
Sifat mekanik
Kekuatan tarik ≥30kgf/mm2
Titik hasil ≥ 18kgf/mm2
Elongasi ((50mm) ≥25%
Kekerasan ((HR30T) ≤ 65
Toleransi ketebalan dinding
+/- 0,08 mm
