Rem Dinding Ganda Dilas Tabung Baja Rendah Karbon Diameter Kecil Untuk Mobil
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 TS16949
Nomor Model:
SAE J527 b
Properti Perdagangan
Jumlah Pesanan Minimum:
3 ton
Harga:
4-6USD/kg
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
Brake Double Wall Low Carbon Steel Tube J527 B Diameter Kecil Untuk Mobil Tabung baja ber dinding ganda yang dilas tembaga terbuat dari strip baja yang dilapisi tembaga di kedua sisinya. Dimensi dan spesifikasi OD mm Ketebalan mm Berat g/m Tekanan jaminan kg/cm3 4.76 0.7 70.28 350 6.00 0.7 91.76 350 ...
Rincian produk
Menyoroti:
pipa baja dilas
,Listrik perlawanan dilas tabung baja
Material:
1008 atau 1010 dll baja karbon rendah
Standard:
SAE J527
OD:
4.76-8.00 mm
WT:
0.7mm
Length:
Panjang lurus atau koil
Assurance Pressure:
350kg/cm3
Deskripsi Produk
Brake Double Wall Low Carbon Steel Tube J527 B Diameter Kecil Untuk Mobil
Tabung baja ber dinding ganda yang dilas tembaga terbuat dari strip baja yang dilapisi tembaga di kedua sisinya.
Dimensi dan spesifikasi
| OD mm | Ketebalan mm | Berat g/m | Tekanan jaminan kg/cm3 |
| 4.76 | 0.7 | 70.28 | 350 |
| 6.00 | 0.7 | 91.76 | 350 |
| 6.35 | 0.7 | 97.75 | 350 |
| 7.00 | 0.7 | 108.75 | 350 |
| 7.14 | 0.7 | 111.17 | 350 |
| 8.00 | 0.7 | 126.31 | 350 |
Toleransi
O.D. dan W.T. +/- 0,08mm
Komposisi Kimia
C ≤ 0,12%
Mn ≤ 0,50%
P≤ 0,04%
S≤ 0,045%
Sifat mekanik
Kekuatan tarik ≥30kgf/mm2
Titik hasil ≥ 18kgf/mm2
Elongasi ((50mm) ≥25%
Kekerasan ((HR30T) ≤ 65
Uji ekspansiAmbil 3 sampel 200mm, memperluas pipa dimensi luar lebih besar dari 25%
Kebersihan internalPartikel dan minyak < 0,194 g/m2
