Ketangguhan Takik Tabung Baja Dilas Untuk Layanan Suhu Rendah Astm A333
Rincian produk
pipa baja dilas
,Listrik perlawanan dilas tabung baja
TORICH ASTM A333 Low Temperature Service with Notch Toughness Pipa Baja Las
TORICH ASTM A333 Low Temperature Service with Notch Toughness Pipa Baja Las
Standar:ASTM A333, ASTM A370, ASTM A999/A999M, ASTM A671, E23, E165, E709
Jangkauan ukuran: OD: 6-420mm
WT: 1-50mm
Panjang: 3-22m
Bahan:Q195, Q215, Q235, Q345, Gr1,Gr3,Gr4,Gr6,Gr7,Gr8,Gr9,Gr10,Gr11
Tes: Uji tegangan transversal atau longitudinal dan uji perataan
Uji dampak
Persyaratan Kimia
| Elemen | Kelas 1 | Kelas 3 | Kelas 4 | Kelas 6 | Kelas 7 | Kelas 8 | Kelas 9 | Kelas 10 | Kelas 11 |
| C, maksimal | 0.30 | 0.19 | 0.12 | 0.30 | 0.19 | 0.13 | 0.20 | 0.20 | 0.10 |
| Mn | 0.40-1.06 | 0.31-0.64 | 0.50-1.05 | 0.29-1.06 | 0.90 maksimal | 0.90 maksimal | 0.40-1.06 | 1.15-1.50 | 0.6 maksimal |
| P, maksimal | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.035 | 0.025 |
| S, maksimal | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.015 | 0.025 |
| Ya. | ... | 0.18-0.37 | 0.08-0.37 | 0.10 menit | 0.13-0.32 | 0.13-0.32 | ... | 0.10-0.35 | 0.35max |
| Tidak | ... | 3.18-3.82 | 0.47-0.98 | 0.40max | 2.03-2.57 | 8.40-9.60 | 1.60-2.24 | 0.25max | 35.0-37.0 |
| Cr | ... | ... | 0.44-1.01 | 0.30max | ... | ... | ... | 0.15max | 0.50max |
| Cu | ... | ... | 0.40-0.75 | 0.40max | ... | ... | 0.75-1.25 | 0.15max | ... |
| Al | ... | ... | 0.04-0.30 | ... | ... | ... | ... | 0.06max | ... |
| V | ... | ... | ... | 0.08 | ... | ... | ... | 0.12 | ... |
| Nb, maksimal | ... | ... | ... | 0.02 | ... | ... | ... | 0.05 | ... |
| Mo, maksimal | ... | ... | ... | 0.12 | ... | ... | ... | 0.05 | 0.50max |
| Co. | ... | ... | ... | ... | ... | ... | ... | ... | 0.50max |
Karakteristik:
Konsentrisitas yang baik Keakuratan tinggi
Kualitas permukaan yang baik Kualitas yang stabil
Toleransi OD dan ID yang baik Kerapatan halus
TORICH Jaminan Kualitas
T: Apakah Anda perusahaan dagang atau produsen?
A: Penemu profesional pipa baja, produsen dan penyedia solusi
T: Berapa lama waktu pengiriman Anda?
A: Umumnya adalah 7-14 hari jika barang ada di stok. atau 30-60 hari jika barang tidak ada di stok, dan itu sesuai dengan kuantitas.
T: Apakah Anda menyediakan sampel? apakah itu gratis atau tambahan?
A: Ya, kami dapat menawarkan sampel gratis tetapi Anda perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A: Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, jangan ragu untuk menghubungi kami
