Tubing Dinding Baja Berat Dinding Permukaan Disesuaikan Jenis Dingin Ditarik OD 5-120mm
Properti Dasar
Tempat Asal:
Zhejiang, China
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
ASTM A333 / A333M
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
800-1100usd/ton
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
6000 ton / bulan
Ringkasan Produk
Permukaan yang disesuaikan Permukaan berat dinding pipa baja tanpa jahitan Tipe tarik dingin OD 5-120mm Permukaan yang disesuaikan Permukaan berat dinding pipa baja tanpa jahitan Tipe tarik dingin OD 5-120mm Bahan: Baja karbon dan paduan, baja ferit Kelas 1A, kelas 3, kelas 4, kelas 6A, kelas 7A ...
Rincian produk
Menyoroti:
thick wall steel pipe
,heavy wall steel pipe
Product Name:
Tubing Dinding Baja Berat Dinding Permukaan Disesuaikan Jenis Dingin Ditarik OD 5-120mm
Keyword:
Tubing Baja Dinding Berat
Type:
Dingin ditarik
Surface:
Disesuaikan
Material:
Gr1, Gr2, Gr3, Gr4, Gr6, Gr7, Gr8, Gr9, Gr10, Gr11
Shape:
Bulat
Usage:
untuk Layanan Suhu Rendah
Brand Name:
TORICH
OD:
5-120mm
WT:
0.4-12mm
Deskripsi Produk
Permukaan yang disesuaikan Permukaan berat dinding pipa baja tanpa jahitan Tipe tarik dingin OD 5-120mm
Permukaan yang disesuaikan Permukaan berat dinding pipa baja tanpa jahitan Tipe tarik dingin OD 5-120mm
Bahan:
Baja karbon dan paduan, baja ferit
Kelas 1A, kelas 3, kelas 4, kelas 6A, kelas 7A
Pembuatan:
Pipa dibuat dengan proses pengelasan dan pengelasan tanpa penambahan logam pengisi dalam operasi pengelasan.
Kelas 4 diproduksi dengan proses yang mulus
Pengolahan panas:
Semua pipa tanpa jahitan dan las, selain kelas 8 dan 11, dirawat panas untuk mengontrol mikrostruktur mereka sesuai dengan metode:
-Normalisasi
- Ditetapkan dan dipanaskan
- Double Normal dan Tempeed
Persyaratan Kimia
| Elemen | Kelas 1 | Kelas 3 | Kelas 4 | Kelas 6 | Kelas 7 | Kelas 8 | Kelas 9 | Kelas 10 | Kelas 11 |
| C, maksimal | 0.30 | 0.19 | 0.12 | 0.30 | 0.19 | 0.13 | 0.20 | 0.20 | 0.10 |
| Mn | 0.40-1.06 | 0.31-0.64 | 0.50-1.05 | 0.29-1.06 | 0.90 maksimal | 0.90 maksimal | 0.40-1.06 | 1.15-1.50 | 0.6 maksimal |
| P, maksimal | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.035 | 0.025 |
| S, maksimal | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.025 | 0.015 | 0.025 |
| Ya. | ... | 0.18-0.37 | 0.08-0.37 | 0.10 menit | 0.13-0.32 | 0.13-0.32 | ... | 0.10-0.35 | 0.35max |
| Tidak | ... | 3.18-3.82 | 0.47-0.98 | 0.40max | 2.03-2.57 | 8.40-9.60 | 1.60-2.24 | 0.25max | 35.0-37.0 |
| Cr | ... | ... | 0.44-1.01 | 0.30max | ... | ... | ... | 0.15max | 0.50max |
| Cu | ... | ... | 0.40-0.75 | 0.40max | ... | ... | 0.75-1.25 | 0.15max | ... |
| Al | ... | ... | 0.04-0.30 | ... | ... | ... | ... | 0.06max | ... |
| V | ... | ... | ... | 0.08 | ... | ... | ... | 0.12 | ... |
| Nb, maksimal | ... | ... | ... | 0.02 | ... | ... | ... | 0.05 | ... |
| Mo, maksimal | ... | ... | ... | 0.12 | ... | ... | ... | 0.05 | 0.50max |
| Co. | ... | ... | ... | ... | ... | ... | ... | ... | 0.50max |
Permukaan yang disesuaikan Permukaan berat dinding pipa baja tanpa jahitan Tipe tarik dingin OD 5-120mm
