Edaran Titanium Alloy Seamless Steel Tube Polishing Permukaan 15m Max Panjang
Rincian produk
stainless steel presisi tubing
,Seamless Carbon Steel tube
TORICH DIN17861 Tabung Titanium dan paduan Titanium Bulat tanpa jahitan
TORICH DIN17861 Tabung Titanium dan paduan Titanium Bulat tanpa jahitan
Standar:GB/T3624, GB/T3625, ASTM B338/ASME SB338, ASTM B861/ASME SB861, DIN17861, ASTM A370
Jangkauan ukuran:OD: 5-89mm
WT: 0,2-5,2 mm
Panjang: 15m maksimal
Bahan:3.7025, 3.7035, 3.7235, 3.7195, 3.7105
Penggunaan:Kondensor dan Penukar Panas
Komposisi Kimia %
| Kelas | N maksimal | C maksimal | H maksimal | Fe maksimal | O maksimal | Sisa | Al | V | Pd | Mo | Cr | Ya. maksimal | S maksimal | Mn maksimal | Cu | lainnya Ers | Tidak | Ti | |
| Setiap maksimal | Total maksimal | ||||||||||||||||||
| 3.7025 | 0.05 | 0.06 | 0.013 | 0.15 | 0.12 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| 3.7035 | 0.05 | 0.06 | 0.013 | 0.20 | 0.18 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| 3.7055 | 0.05 | 0.06 | 0.013 | 0.25 | 0.25 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| 3.7235 | 0.05 | 0.06 | 0.013 | 0.20 | 0.18 | 0.1 | 0.4 | - | - | 0.15-0.25 | - | - | - | - | - | - | - | - | saldo |
| 3.7195 | 0.04 | 0.05 | 0.015 | 0.30 | 0.12 | 0.1 | 0.4 | 2.5-3.5 | 2.0-3.0 | - | - | - | - | - | - | - | - | - | saldo |
| 3.7105 | 0.03 | 0.08 | 0.013 | 0.25 | 0.25 | 0.1 | 0.4 | - | - | - | 0.2-0.4 | - | - | - | - | - | - | 0.6-0.9 | saldo |
Sifat Mekanis
| Kelas | TS ((Mpa) | YS(Mpa) | E ((%), min |
| 3.7025 | 290-450 | ≥ 180 | 30 |
| 3.7035 | 390-540 | ≥ 250 | 22 |
| 3.7055 | 460-590 | ≥ 320 | 18 |
| 3.7235 | 390-540 | ≥ 250 | 22 |
| 3.7195 | ≥ 620 | ≥520 | 15 |
| 3.7105 | ≥ 480 | ≥ 345 | 18 |
Karakteristik:
Konsentrisitas yang baik Keakuratan tinggi
Kualitas permukaan yang baik Kualitas yang stabil
Toleransi OD dan ID yang baik Kerapatan halus
TORICH Jaminan Kualitas
T: Apakah Anda perusahaan dagang atau produsen?
A: Penemu profesional pipa baja, produsen dan penyedia solusi
T: Berapa lama waktu pengiriman Anda?
A: Umumnya adalah 7-14 hari jika barang ada di stok. atau 30-60 hari jika barang tidak ada di stok, dan itu sesuai dengan kuantitas.
T: Apakah Anda menyediakan sampel? apakah itu gratis atau tambahan?
A: Ya, kami dapat menawarkan sampel gratis tetapi Anda perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A: Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, jangan ragu untuk menghubungi kami
