Torich Round Seamless Stainless Steel Tube Untuk Penukar Panas 10 - 76mm OD
Properti Dasar
Tempat Asal:
Zhejiang, Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001, ISO14001, ISO16949
Nomor Model:
GB / T30073
Properti Perdagangan
Jumlah Pesanan Minimum:
5tons
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
50000tons per tahun
Ringkasan Produk
TORICH GB/T30073 tabung stainless steel austenit tanpa jahitan untuk penukar panas Standar:GB/T30073 Bahan:06Cr19Ni10, 022Cr19Ni10, 022Cr19Ni10N, 06Cr17Ni12Mo2, 022Cr17Ni12Mo2,022Cr17Ni12Mo2N, 06Cr18Ni11Ti OD:10-76mm WT:0.7-4.0mm Penggunaan: Penukar panas di pembangkit listrik tenaga nuklir ...
Rincian produk
Menyoroti:
stainless steel putaran tabung
,diameter besar tabung baja stainless
Product Name:
TORICH Tabung Stainless Steel Austenitic Mulus untuk Penukar Panas
Keyword:
tabung baja stainless
Standard:
GB / T30073
Material:
06Cr19Ni10,022Cr19Ni10,022Cr19Ni10N, 06Cr17Ni12Mo2,022Cr17Ni12Mo2
Section Shape:
Bentuk bulat
Surface:
Polandia
OD:
10-76mm
WT:
0.7-4.0mm
Length:
sesuai persyaratan pelanggan'
Usage:
Penukar panas di pembangkit listrik tenaga nuklir
Deskripsi Produk
TORICH GB/T30073 tabung stainless steel austenit tanpa jahitan untuk penukar panas
Standar:GB/T30073
Bahan:06Cr19Ni10, 022Cr19Ni10, 022Cr19Ni10N, 06Cr17Ni12Mo2,
022Cr17Ni12Mo2,022Cr17Ni12Mo2N, 06Cr18Ni11Ti
OD:10-76mm
WT:0.7-4.0mm
Penggunaan: Penukar panas di pembangkit listrik tenaga nuklir
Komposisi kimia:
| Kelas | Kode nomor seragam | Komposisi kimia % | |||||||||||
| C | Ya. | Mn | P | S | Cr | Tidak | Mo | Cu | B | N | Ti | ||
| 06Cr19Ni10 | S30408 | 0.06 | 0.75 | 2.00 | 0.030 | 0.015 | 17.00-20.00 | 9.00-12.00 | - | 1.00 | 0.0018 | - | - |
| 022Cr19Ni10 | S30403 | 0.030 | 0.75 | 2.00 | 0.030 | 0.015 | 18.00-20.00 | 9.00-12.00 | - | 1.00 | 0.0018 | - | - |
| 022Cr19Ni10N | S30453 | 0.035 | 1.00 | 2.00 | 0.030 | 0.015 | 18.50-20.00 | 9.00-10.00 | - | 1.00 | 0.0018 | 0.08 | - |
| 06Cr17Ni12Mo2 | S31608 | 0.07 | 0.75 | 2.00 | 0.030 | 0.015 | 17.00-19.00 | 10.00-14.00 | 2.00-2.50 | 1.00 | 0.0018 | - | - |
| 022Cr17Ni12Mo2 | S31603 | 0.030 | 0.75 | 2.00 | 0.030 | 0.015 | 17.00-19.00 | 10.00-14.00 | 2.00-2.50 | 1.00 | 0.0018 | - | - |
| 022Cr17Ni12Mo2N | S31653 | 0.035 | 1.00 | 2.00 | 0.030 | 0.015 | 17.00-18.00 | 11.50-12.50 | 2.25-2.75 | 1.00 | 0.0018 | 0.08 | - |
| 06Cr18Ni11Ti | S32168 | 0.08 | 1.00 | 2.00 | 0.030 | 0.015 | 17.00-19.00 | 9.00-12.00 | - | 1.00 | 0.0018 | - | 5C-0.70 |
Sifat Mekanis:
| Bahan | Kode nomor seragam
|
Tekanan suhu kamar
| 350°C Kekuatan tarik suhu tinggi
| ||||
| kekuatan perpanjangan plastisitas MPa | Kekuatan tarik kekuatan MPa | Perpanjangan % | kekuatan perpanjangan plastisitas MPa | Kekuatan tarik kekuatan MPa | Perpanjangan % | ||
| 06Cr19Ni10 | S30408 | 210 | 520 | 45 | 125 | 394 | 7.93 |
| 022Cr19Ni10 | S30403 | 175 | 490 | 45 | 105 | 350 | 7.90 |
| 022Cr19Ni10N | S30453 | 220 | 520 | 45 | 125 | 394 | 7.93 |
| 06Cr17Ni12Mo2 | S31608 | 210 | 520 | 45 | 130 | 445 | 8.00 |
| 022Cr17Ni12Mo2 | S31603 | 175 | 490 | 45 | 105 | 355 | 8.00 |
| 022Cr17Ni12Mo2N | S31653 | 220 | 520 | 45 | 130 | 400 | 8.04 |
| 06Cr18Ni11Ti | S32168 | 210 | 520 | 35 | 125 | 394 | 8.03 |
Tes:
Uji perataan Uji tekanan residual
Uji pembakaran Uji ultrasonik
Uji Metallografi Uji arus Eddy
TORICH GB/T30073 tabung stainless steel austenit tanpa jahitan untuk penukar panas di pembangkit listrik tenaga nuklir
