Welded Drawn Over Mandrel Tubing Astm A 513-6 SSID Khusus Diameter Dalam Halus
Rincian produk
Presisi pipa baja
,Pipa seamless presisi
ASTM A 513 -6 SSID Tabung dalam diameter halus khusus
Detail cepat
| Bahan | Baja karbon |
| Nama produk | Tersaldur ditarik di atas mandrel tabung Astm A 513-6 SSID Diameter dalaman halus khusus |
| Standar | ASTM A513 T5 T6 ((SSID),DIN2393,EN10305-2 |
| Bahan | 1010,1018,1020,1026St52 |
Spesifikasitabung baja presisi untuk mata air gas:
ASTM A513 T5 T6 ((SSID),DIN2393,EN10305Tabung HPS (SSID) sesuai dengan DIN EN 10305-2
Kelas:1010,1018,1020,1026St52
Rentang ukuran:0.375 "-6" OD sampai 0,25 "Dinding.
Metode produksi:Selap ditarik -Over-Mandrel
Tabung SSID Tabung baja presisi tinggi Bentuk: OD bulat dan ID dengan kelancaran sempurna maksimal 0,8μm
Teknik Manufaktur Pipa Baja SSID Presisi Tinggi: Membuat Pipa Dengan Cold Drawn dan Cold Rolling
SSID Tubing Kondisi Pengiriman Presisi Tinggi:
A.W.H.R.
A.W.C.R.
S.D.C.R.
M.D.
S.S.I.D
| Kelas baja dan komposisi kimia: | |||||||
| Baja | C | Mn | P | S | Ya. | Cr | Mo |
| Kelas | maksimal | maksimal | maksimal | maksimal | menit | ||
| 1008 | 0.10 | 0.30-0.50 | 0.040 | 0.050 | |||
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | |||
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | |||
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1035 | 0.32-0.38 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1045 | 0.43-0.50 | 0.60-0.90 | 0.040 | 0.050 | |||
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| Kelas | kondisi | Ultimat | Hasil | Perpanjangan | Rockwell |
| Kekuatan | Kekuatan | Kekerasan | |||
| Ksi Mpa | Ksi Mpa | % | Skala B | ||
| 1020 | HR | 50 345 | 32 221 | 25 | 55 |
| CW | 70 483 | 60 414 | 5 | 75 | |
| SR | 65 448 | 50 345 | 10 | 72 | |
| A | 48 331 | 28 193 | 30 | 50 | |
| N | 55 379 | 34 234 | 22 | 60 | |
| 1025 | HR | 55 379 | 35 241 | 25 | 60 |
| CW | 75 517 | 65 448 | 5 | 80 | |
| SR | 70 483 | 55 379 | 8 | 75 | |
| A | 53 365 | 30 207 | 25 | 57 | |
| N | 55 379 | 36 248 | 22 | 60 | |
| 1035 | HR | 65 448 | 40 276 | 20 | 72 |
| CW | 85 586 | 75 517 | 5 | 88 | |
| SR | 75 517 | 65 448 | 8 | 80 | |
| A | 60 414 | 33 228 | 25 | 67 | |
| N | 65 448 | 40 276 | 20 | 72 | |
| 1045 | HR | 75 517 | 45 310 | 15 | 80 |
| CW | 90 621 | 80 552 | 5 | 90 | |
| SR | 80 552 | 70 483 | 8 | 85 | |
| A | 65 448 | 35 241 | 20 | 72 | |
| N | 75 517 | 48 331 | 15 | 80 | |
| 4130 | HR | 90 621 | 70 483 | 20 | 89 |
| SR | 105 724 | 85 586 | 10 | 95 | |
| A | 75 517 | 55 379 | 30 | 81 | |
| N | 90 621 | 60 414 | 20 | 89 | |
| 4140 | HR | 120 855 | 90 310 | 15 | 100 |
| SR | 120 855 | 100 689 | 10 | 100 | |
| A | 80 552 | 60 414 | 25 | 85 | |
| N | 120 855 | 90 621 | 20 | 100 |
Tabung SSID Presisi Tinggi Kondisi pengiriman:
1A.W.H.R. "sebagai las" dari baja bergelombang panas
2A.W.C.R. "sebagai las" dari baja yang digulung dingin
3S.D.C.R. "sink-drawn", baja yang digulung dingin
4. M.D. mandrel ditarik
5. S.S.I.D. diameter dalaman halus khusus
Karakteristik tabung dan pipa SSID
Toleransi diameter dalam H9 - H10, tergantung pada diameter
Karat maksimal 0,8 μm
Diameter luar sesuai DIN EN 10305-2
Kejujuran 1:1.000 mm
Eksentrisitas maksimum 4 %
Kondisi + C sesuai DIN EN 10305-2
Kondisi pengirimantabung presisi baja:Ditarik dingin tanpa perawatan panas.
Aplikasi:Dalam sebagian besar aplikasi kritis dalam pembangkit listrik, otomotif dan teknik umum.
Hal ini dapat digunakan secara langsung dalam aplikasi silinder pneumatik hidrolik.
Karakteristik: presisi, dapat mengurangi biaya bahan.
Tes:Uji arus Eddy.
Tes ultrasonik.
-
