Bs3059 Gr360 Hot Finished Tube Seamless, Tabung Penukar Panas Baja Karbon
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO 14001
Nomor Model:
BS3059
Properti Perdagangan
Jumlah Pesanan Minimum:
5
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
50000tons/tahun
Ringkasan Produk
BS 3059 Gr 360 Tabung penukar panas baja karbon untuk boiler baja dan tabung superheater Nama produk:BS 3059 Boiler baja dan tabung superheater Tabung baja tahan karat karbon, paduan dan austenit dengan sifat suhu tinggi tertentu Ukuran Diameter 5-420mm Ketebalan dinding 0,5-50 mm Panjang Pada ...
Rincian produk
Menyoroti:
Pipa baja mulus
,stainless steel presisi tubing
Keyword:
Tabung Baja Karbon Seamless
OD:
4-420mm
WT:
0.5-50mm
Length:
1-12m
Material:
20 # .45 #
Shape:
Bulat
Deskripsi Produk
BS 3059 Gr 360 Tabung penukar panas baja karbon untuk boiler baja dan tabung superheater
Nama produk:BS 3059 Boiler baja dan tabung superheater
Tabung baja tahan karat karbon, paduan dan austenit dengan sifat suhu tinggi tertentu
Ukuran
Diameter 5-420mm
Ketebalan dinding 0,5-50 mm
Panjang Pada permintaan
Aplikasi:untuk boiler dan superheater
Metode produksi:tanpa jahitan, dilas
Kondisi pengiriman:Hot selesai, dingin selesai
| Komposisi Kimia % max | |||||||||
| Kelas baja | C | Ya. | Mn | P | S | Cr | Mo | Tidak | lainnya |
| 360 | 0.17 | 0.10-0.35 | 0.40-0.80 | 0.035 | 0.035 | - | - | - | - |
| 440 | 0.12-0.18 | 0.10-0.35 | 0.90-1.20 | 0.035 | 0.035 | - | - | - | - |
| 243 | 0.12-0.20 | 0.10-0.35 | 0.40-0.80 | 0.035 | 0.035 | - | 0.25-0.35 | - | Al 0.012 |
| 620-460 | 0.10-0.15 | 0.10-0.35 | 0.4-0.7 | 0.03 | 0.03 | 0.7-1.10 | 0.45-0.65 | - | Al 0.020 |
| 622-490 | 0.08-0.15 | 0.5 | 0.4-0.7 | 0.03 | 0.03 | 2.00-2.50 | 0.90-1.20 | - | Al 0.020 |
| 629-470 | 0.15 | 0.25-1.00 | 0.30-0.60 | 0.03 | 0.03 | 8.00-10.00 | 0.90-1.10 | - | Al 0.020 |
| 629-590 | |||||||||
| 762 | 0.17-0.23 | 0.50 | 1.00 | 0.03 | 0.03 | 10.00-12.50 | 0.80-1.20 | 0.30-0.80 | vanadium 0.25-0.35 |
| Catatan:243,620-460,622-490,629-470,629-590 elemen sisa berikut tidak boleh melebihi Ni,0.30%; Cu,00,25%;Sn,00,03% | |||||||||
| Properti Mekanis Min | |||
| Kelas baja | Kekuatan tarik Mpa | Titik yield atau tegangan bukti Mpa | Elongasi % |
| 360 | 360-500 | 235 | 24 |
| 440 | 440-580 | 245 | 21 |
| 243 | 480-630 | 275 | 22 |
| 620-460 | 460-610 | 180 | 22 |
| 622-490 | 490-640 | 275 | 20 |
| 629-470 | 470-620 | 185 | 20 |
| 629-590 | 590-740 | 400 | 18 |
| 762 | 720-870 | 470 | 15 |
| Kondisi pengiriman | kelas baja | Kondisi pasokan akhir | Suhu perawatan panas |
| 360,440 ((tidak berurutan selesai panas) | Hot selesai | - | |
| 360,440 ((tanpa jahitan selesai dingin) | normal | 880-940 | |
| 243 ((semua kondisi manufaktur) | normal | 900-960 | |
| 622-490 ((tanpa jahitan) | di-normalized+tempered | normal 900-960 diperkuat680-750 | |
| 629-470 ((tanpa jahitan) | dipanaskan | 850-950 | |
| 629-590 ((tanpa jahitan) | di-normalized+tempered | Normal 900-1000 diperkuat 700-800 | |
| 762 ((tidak berjuit) | di-normalized+tempered | di normalkan1020-1070 diperkuat730-780 |
