Penukar Panas / Kondensor Tabung Baja Presisi Astm A179 Baja Karbon Rendah
Rincian produk
Presisi pipa baja
,Pipa seamless presisi
Panas penukar / kondensor ASTM A179 tabung baja karbon rendah tanpa jahitan yang ditarik dingin
ASTM A179 tabung penukar panas baja rendah karbon dan tabung kondensor
Tabung penukar panas baja rendah karbon yang ditarik dingin tanpa jahitan dan tabung kondensor
| Nama produk:: | Torich Cold Drawn Seamless Alloy Steel Tube dengan Karbon ASTM A179 SA178, A179, A192, A210, SA213, SA214 | Bahan:: | SA178, A179, A192, A210, SA213, SA214 |
|---|---|---|---|
| Permukaan: | Dengan minyak anti karat | Aplikasi:: | Struktur, suhu tinggi, pipa dan tabung transportasi cairan untuk boiler tekanan tinggi |
| Bentuk: | Bulat | OD: | 3.2-76.2mm |
| WT:: | 0.5-200mm | Panjangnya: | 4-12,5m |
| Toleransi: | Menurut tabel berikut atau permintaan pelanggan. | Spesifikasi: | Panjang Umum:4-12,5m |
Aplikasi:
- Untuk Boiler,
- Superheater,
- Tubular Heat-Exchangers,
- Kondensator
- Peralatan transfer panas
Tabung lentur U sesuai dengan permintaan pelanggan
Bahan: Baja rendah karbon
Produksi: Tanpa jahitan ditarik dingin
Jangkauan ukuran:OD:3.2-76.2mm W.T.:1-15mm L: sesuai dengan kebutuhan pelanggan.
Kelas baja dan komposisi kimia:
| C | 0.06-0.18 | |
| Mn | 0.27-0.63 | |
| P | ≤ 0.035 | |
| S | ≤ 0.035 |
Sifat Mekanis
Stretch Tensile: min ksi[Mpa] 47[325]
Titik Hasil: min ksi[Mpa] 26[180]
Elongasi: ≥35%
Kekerasan: ≤ 72HRB
Pengolahan panas:
Tabung dirawat panas setelah penarik dingin terakhir melewati suhu 1200 ° F ((650 ° C) atau lebih tinggi
Perbaikan permukaan:
Tubes akhir bebas skala.
Kami memiliki perawatan panas normal dengan permukaan hitam.
Mempunyai penggilingan terang dengan permukaan abu-abu dan terang.
Pengujian Mekanis:
Tes perataan
Uji pembakaran
Uji Flange
Tes Kekerasan
Rincian kemasan:
Pengemasan dalam kotak kayu, bundel heksagonal atau cara yang layak laut lainnya.
-
