Polishing Permukaan Seamless Steel Tube Astm B861 Bahan Baja Paduan Titanium
Rincian produk
Pipa baja mulus
,Seamless Carbon Steel tube
permukaan polishing TORICH ASTM B861/ASME SB861 tabung baja paduan titanium tanpa jahitan
Standar:GB/T3624, GB/T3625, ASTM B338/ASME SB338, ASTM B861/ASME SB861, DIN17861, ASTM A370
Jangkauan ukuran:OD: 5-168mm
WT: 0,2-5,2 mm
Panjang: 15m maksimal
Bahan:Kelas 1, Kelas 2, Kelas 7, Kelas 9, Kelas 12, Kelas 16
Penggunaan:Kondensor dan Penukar Panas
Komposisi Kimia %
| Kelas | N maksimal | C maksimal | H maksimal | Fe maksimal | O maksimal | Sisa | Al | V | Pd | Mo | Cr | Ya. maksimal | S maksimal | Mn maksimal | Cu | lainnya Ers | Tidak | Ti | |
| Setiap maksimal | Total maksimal | ||||||||||||||||||
| Gr.1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | 0.1 | 0.4 | - | - | - | - | - | - | - | - | - | - | - | saldo |
| Gr.7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | 0.12-0.25 | - | - | - | - | - | - | - | - | saldo |
| Gr.9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 0.1 | 0.4 | 2.5-3.5 | 2.0-3.0 | - | - | - | - | - | - | - | - | - | saldo |
| Gr.12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | - | 0.2-0.4 | - | - | - | - | - | - | 0.6-0.9 | saldo |
| Gr.16 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.1 | 0.4 | - | - | 0.04-0.08 | - | - | - | - | - | - | - | 0.6-0.9 | saldo |
Sifat Mekanis
| Kelas | TS ((Mpa) | YS(Mpa) | E ((%), min |
| Gr.1 | ≥ 240 | 138-310 | 24 |
| Gr.2 | ≥ 345 | 275-450 | 20 |
| Gr.3 | ≥ 450 | 380-550 | 18 |
| Gr.7 | ≥ 345 | 275-450 | 20 |
| Gr.9 | ≥ 620 | ≥ 483 | 15 |
| Gr.12 | ≥ 483 | ≥ 345 | 18 |
| Gr.16 | ≥ 345 | 275-450 | 20 |
Karakteristik:
Konsentrisitas yang baik Keakuratan tinggi
Kualitas permukaan yang baik Kualitas yang stabil
Toleransi OD dan ID yang baik Kerapatan halus
TORICH Jaminan Kualitas
Torich International Co., Ltd adalah produsen profesional dan eksportir bahan pipa baja.yang memiliki pabrik pipa baja tanpa jahitan dengan karbon dan baja paduan kelas, Tabung baja presisi yang dilas, tabung baja DOM, tabung baja tahan karat yang tersusun dan tersusun dengan nikel dan baja paduan.
Pabrik kami didirikan sejak tahun 1997, dengan nama Haiyan Sanxin Steel Pipe Co, Ltd.Para teknisi pabrik memiliki pengalaman teknik yang besar dalam industri pipa baja selama lebih dari 20 tahun, yang menguasai teknologi produksi untuk Cold Drawing dan Cold Rolling. jadi kami memiliki tim teknis yang kuat dan kemampuan manufaktur.
-
