Grade N06625 Alloy Steel Seamless Pipe Astm B444 Untuk Mesin Pesawat
Properti Dasar
Tempat Asal:
Zhejiang China
Nama merek:
TORICH
Sertifikasi:
ISO
Nomor Model:
ASTM B444
Properti Perdagangan
Jumlah Pesanan Minimum:
100 kg
Harga:
35 USD per Kg
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
10000 Ton per tahun
Ringkasan Produk
ASTM B444 Inconel 625 pipa baja nikel tanpa jahitan UNS N06625 2.4856 paduan 625 Inconel 625 Pipa Tanpa Jahit ASTM B444 Ukuran: Bentuk Ukuran (OD,T) Tabung Pipa Diameter luar: Φ10 ~ 300mm Ketebalan dinding:THK 1 ~ 80mm Panjang: Dapat disesuaikan Bar Mempertukarkan Lembar/Serit Kawat Pipa ASTM B446 ...
Rincian produk
Menyoroti:
inconel 600 tube
,inconel 718 tube
Grade::
N06625
Type::
Pipa Nikel
Application::
Mesin pesawat terbang
Ni (Min)::
58
Resistance (ΜΩ.M)::
1.5
Elongation (≥ %)::
30%
Ultimate Strength (≥ MPa)::
965
Powder Or Not::
Bukan bubuk
Model Number::
Pipa baja paduan inconel
Port:
SHANGHAI / NINGBO
Deskripsi Produk
ASTM B444 Inconel 625 pipa baja nikel tanpa jahitan UNS N06625 2.4856 paduan 625
Inconel 625 Pipa Tanpa Jahit ASTM B444 Ukuran:
| Bentuk | Ukuran (OD,T) |
| Tabung Pipa | Diameter luar: Φ10 ~ 300mm Ketebalan dinding:THK 1 ~ 80mm Panjang: Dapat disesuaikan |
| Bar | Mempertukarkan | Lembar/Serit | Kawat | Pipa | |||||
| ASTM B446 | ASTM B564 | ASTM B443 | - | ASTM B444 | |||||
| ASTM B704 | |||||||||
| ASTM B705 |
Inconel 625 pipa tanpa jahitan ASTM B444 Komposisi kimia:
| Tidak | Fe | Al | Cr | C | Ti | Mo | Mn | Nb | Ya. | Co. | |
| Min | 58 | - | - | 20 | - | - | 8 | - | 3.15 | - | - |
| Maksimal | - | 5.0 | 0.4 | 23 | 0.1 | 0.4 | 10 | 0.5 | 4.15 | 0.5 | 1.0 |
Inconel 625 Pipa Tanpa Jahit ASTM B444 Sifat Mekanis:
| Kekuatan tarik σb/Mpa | Kekuatan Hasil σp0.2/Mpa | Perpanjangan σ5 /% |
| 760 | 345 | 30 |
