Bentuk Bulat Seamless Mechanical Tubing Astm B111 Dengan Diameter Luar 2 - 100mm
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO LR TUV
Nomor Model:
ASTM B111
Properti Perdagangan
Jumlah Pesanan Minimum:
0.5tons
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L/C, T/T
Kemampuan Penyediaan:
30000tons per tahun
Ringkasan Produk
Tabung baja tanpa jahitan ASTM B111 UNSC68700 UNSC44500 Tembaga dan tembaga paduan kondensator tanpa jahitan tabung dan ferrule stok Kualitas yang baik untuk penukar panas Ukuran umum sebagai OD 19.0525 tahun.12.7, WT 1.651.2452.11. Persyaratan kimia Tembaga atau paduan tembaga UNS No. Tembaga ...
Rincian produk
Menyoroti:
Pipa baja mulus
,stainless steel presisi tubing
Material:
UNSC68700 UNSC44500
Standard:
ASTM B111
OD:
2-100mm
WT:
0.1-20mm
Length:
12maks
Production Method:
Digambar dingin + Mulus
Shape:
Bulat
Deskripsi Produk
Tabung baja tanpa jahitan ASTM B111 UNSC68700 UNSC44500
Tembaga dan tembaga paduan kondensator tanpa jahitan tabung dan ferrule stok
Kualitas yang baik untuk penukar panas
Ukuran umum sebagai OD 19.0525 tahun.12.7, WT 1.651.2452.11.
| Persyaratan kimia | |||||||||||||
| Tembaga atau paduan tembaga UNS No. | Tembaga | Kaleng | Al | Tidak termasuk Co | Pb max | Fe max | Zn maksimal | Mn max | Sebagai | Sb | P maksimal | Cr | Unsur bernama lainnya |
| C44300 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | sisanya | 0.02-0.06 | |||||||
| C44400 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | sisanya | 0.02-0.10 | |||||||
| C44500 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | sisanya | 0.02-0.10 | |||||||
| C60800 | sisanya | 5.0-6.5 | 0.1 | 0.1 | 0.02-0.35 | ||||||||
| C61300 | sisanya | 0.20-0.50 | 6.0-7.5 | 0.15 maksimal | 0.01 | 2.0-3.0 | 0.1 | 0.2 | 0.015 | ||||
| C61400 | sisanya | 6.0-8.0 | 0.01 | 1.5-3.5 | 0.2 | 1.0 | 0.015 | ||||||
| C68700 | 76.0-79.0 | 1.8-2.5 | 0.07 | 0.06 | sisanya | 0.02-0.06 | |||||||
| C70400 | sisanya | 4.8-6.2 | 0.05 | 1.3-1.7 | 1.0 | 0.30-0.80 | |||||||
| C70600 | sisanya | 9.0-11.0 | 0.05 | 1.0-1.8 | 1.0 | 1.0 | |||||||
| C70620 | 86.5 menit | 9.0-11.0 | 0.02 | 1.0-1.8 | 0.5 | 1.0 | 0.02 | C.05 maksimal S.02 maksimal | |||||
| C71000 | sisanya | 19.0-23.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | |||||||
| C71500 | sisanya | 29.0-33.0 | 0.05 | 0.4-1.0 | 1.0 | 1.0 | |||||||
| C71520 | 65.0 menit | 29.0-33.0 | 0.02 | 0.4-1.0 | 0.5 | 1.0 | 0.02 | C.05 maksimal S.02 maksimal | |||||
| C71640 | sisanya | 29.0-32.0 | 0.05 | 1.7-2.3 | 1.0 | 1.5-2.5 | C.06 maksimal S.03 maksimal | ||||||
| C72200 | sisanya | 15.0-18.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | 0.30-0.70 | Ya, aku tahu.03 maksimal Ti.03 maksimal | |||||
