Pipa Stainless Steel Bentuk Bulat Untuk Industri Kimia 304 316 310S
Properti Dasar
Tempat Asal:
Cina
Nama merek:
TORICH
Sertifikasi:
ISO 9001 ISO 14001 TS 16949 EN 10204.3.1 LR KR
Nomor Model:
304 316 310S
Properti Perdagangan
Jumlah Pesanan Minimum:
1 TON
Harga:
USD 600-800 per ton
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 ton per tahun
Ringkasan Produk
Pipa las baja tahan karat untuk industri kimia 304 316 310S AplikasiIndustri Kimia ukuran:L-10-12m OD-6-219mm WT-2-50mm kelas baja:12Cr18Ni9,06Cr19Ni10,022Cr19Ni10,06Cr19Ni10N,06Cr19Ni9NbN,022Cr19Ni10N,06Cr23Ni13,06Cr25Ni20,06Cr17Ni12Mo2,022Cr17Ni12Mo2,07Cr17Ni12Mo2,06Cr17Ni12Mo2,06Cr17Ni12Mo2Ti ...
Rincian produk
Menyoroti:
pipa baja dilas
,Listrik perlawanan dilas tabung baja
Product Name:
Pipa Las Stainless Steel untuk Industri Kimia 304 316 310S
Keyword:
pipa baja dilas
Material:
302, 304.304L, 316.316L
Surface:
Polandia
Type:
Pipa Baja Bulat Seamless
Application:
transportasi cairan
Shape:
Bentuk bulat
Length:
10-12 m
OD:
6-219mm
WT:
2-50mm
Deskripsi Produk
Pipa las baja tahan karat untuk industri kimia 304 316 310S
AplikasiIndustri Kimia
ukuran:L-10-12m OD-6-219mm WT-2-50mm
kelas baja:12Cr18Ni9,06Cr19Ni10,022Cr19Ni10,06Cr19Ni10N,06Cr19Ni9NbN,022Cr19Ni10N,06Cr23Ni13,06Cr25Ni20,06Cr17Ni12Mo2,022Cr17Ni12Mo2,07Cr17Ni12Mo2,06Cr17Ni12Mo2,06Cr17Ni12Mo2Ti
Metode pembuatan:Penggulung panas (memperset, memperluas) atau menggulung dingin (penggulung)
Negara Pengiriman:Perawatan panas dan pemurnian
Toleransi Diameter Luar dan Ketebalan DindingSatuan: mm
| Penggulung panas (ekstrusi, ekspansi) tabung baja | Tabung baja yang ditarik dingin (rolling) | ||||||
| Dimensi | Toleransi | Dimensi | Toleransi | ||||
| PA Kelas Biasa | PC Tingkat Tinggi | PA Kelas Biasa | PC Tingkat Tinggi | ||||
| Diameter luar nominal D | 68 ~ 159 | ± 1,25%D | ± 1%D | Diameter luar nominal D | 6 ~ 10 | ± 0.20 | ± 0.15 |
| > 10 ~ 30 | ± 0.30 | ± 0.20 | |||||
| > 30 ~ 50 | ± 0.40 | ± 0.30 | |||||
| > 50 ~ 219 | ± 0,85%D | ± 0,75%D | |||||
| >159 | ±1,5%D | >219 | ± 0,9%D | ± 0,8%D | |||
| Ketebalan dinding nominal S | < 15 | +15%S - 12,5% | ± 12,5%S | Ketebalan dinding nominal S | ≤3 | ±12%S | ± 10%S |
| ≥ 15 | +20%S -15%S | >3 | + 12,5%S -10%S | ± 10%S | |||
Toleransi Ketebalan Tembok MinimalSatuan: mm
| Metode Produksi | Dimensi | Toleransi | |
| PA Kelas Biasa | PC Tingkat Tinggi | ||
| Penggulung panas (ekstrusi, ekspansi) tabung baja W-H | Smenit< 15 | +25%Smenit 0 | + 22,5%Smenit 0 |
| Smenit≥ 15 | +32,5%Smenit 0 | ||
| Tabung baja yang ditarik dingin (rolling) WC | Semua Kekakuan Dinding | +22%Smenit 0 | +20%Smenit 0 |
Perbandingan Kelas Baja Rinsless
| Tidak, tidak. | GB/T 20878-2007 | ASTM A 959-09 | JIS G4303-2005 JIS G 4311-1991 | ISO/TS 15510:2003 ISO 4955:2005 | EN 10088:1-2005 | PTN 5632-1972 | |
| Unified Digital Code (Kode Digital Bersatu) | Kelas | ||||||
| 1 | S30210 | 12Cr18Ni9 | S30200,302 | SUS302 | X10CrNi18-8 | X10CrNi18-8,1.4310 | 12X18H9 |
| 2 | S30408 | 06Cr19Ni10 | S30400,304 | SUS304 | X5CrNi18-9 | X5CrNi18-10,1.4301 | - |
| 3 | S30403 | 022Cr19Ni10 | S30403,304L | SUS304L | X2CrNi19-11 | X2CrNi19-11,1.4306 | 03X18H11 |
| 4 | S30458 | 06Cr19Ni10N | S30451,304N | SUS304N1 | X5CrNiN18-8 | X5CrNiN19-9,1.4315 | - |
| 5 | S30478 | 06Cr19Ni9NbN | S30452,XM-21 | SUS304N2 | - | - | - |
| 6 | S30453 | 022Cr19Ni10N | S30453,304LN | SUS304LN | X2CrNiN18-9 | X2CrNiN18-10,1.4311 | - |
| 7 | S30908 | 06Cr23Ni13 | S30908,309S | SUS309S | X12CrNi23-13 | X12CrNi23-13,1.4833 | - |
| 8 | S31008 | 06Cr25Ni20 | S31008,310S | SUS310S | X8CrNi25-21 | X8CrNi25-21,1.4845 | 10X23H18 |
| 9 | S31608 | 06Cr17Ni12Mo2 | S31600,316 | SUS316 | X5CrNiMo17-12-2 | X5CrNiMo17-12-2,1.4401 | - |
| 10 | S31603 | 022Cr17Ni12Mo2 | S31603,316L | SUS316L | X2CrNiMo17-12-2 | X2CrNiMo17-12-2,1.4404 | 03X17H14M3 |
| 11 | S31609 | 07Cr17Ni12Mo2 | S31609,316H | - | - | X3CrNiMo17-13-3,1.4436 | - |
| 12 | S31668 | 06Cr17Ni12Mo2Ti | S31635,316Ti | SUS316Ti | X6CrNiMoTi17-12-2 | X6CrNiMoTi17-12-2,1.4571 | 08X17H13M2T |
