Panjang Disesuaikan Pipa Baja Dilas HC340 HC420 10-50mm OD Untuk Suku Cadang Mobil
Properti Dasar
Tempat Asal:
Zhejiang, China
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
HC340 HC420
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
1000-1300 usd per ton
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
50000 TON PER TAHUN
Ringkasan Produk
Tabung baja las 19.1mmX1.2mm HC340 HC420 tabung baja paduan untuk suku cadang mobil dari TORICH Rincian produk Baja paduan rendah kekuatan tinggi Bahan: HC340/HC340LA, HC420/HC420LC dll Ukuran OD: 10mm ~ 50mm WT: 0.5mm ~ 2.5mm Panjang: sesuai dengan kebutuhan pelanggan Teknik: Cold Draw/Cold Rolled, ...
Rincian produk
Menyoroti:
pipa baja dilas
,Listrik perlawanan dilas tabung baja
Product Name:
HC340 HC420 Alloy Steel Tube untuk Suku Cadang Mobil
Keyword:
HC340 HC420 Tabung Baja Paduan
Application:
untuk Suku Cadang Mobil
Material:
HC340 HC420 HC2201 HC180Y dll
Shape:
Bulat
Type:
Dingin ditarik / dingin digulung / ERW
Brand:
UNTUK KAYA
Length:
Disesuaikan
OD:
10-50mm
WT:
0,5-2.5mm
Deskripsi Produk
Tabung baja las 19.1mmX1.2mm HC340 HC420 tabung baja paduan untuk suku cadang mobil dari TORICH
Rincian produk
Baja paduan rendah kekuatan tinggi
Bahan: HC340/HC340LA, HC420/HC420LC dll
Ukuran OD: 10mm ~ 50mm WT: 0.5mm ~ 2.5mm Panjang: sesuai dengan kebutuhan pelanggan
Teknik: Cold Draw/Cold Rolled, ERW
Toleransi: Dapat dikontrol dalam OD / Ketebalan +/- 0,1mm
Aplikasi: Untuk suku cadang mobil
Uji: Uji ketegangan, uji pembakaran, uji flange, uji terbalik, uji kekerasan, uji listrik hidrostatik atau tidak merusak
| Kelas baja | C | Mn | P | S | Alt | Ya. | Ti | Nb |
| maksimal | ||||||||
| HC2201 | 0.06 | 0.8 | 0.04 | 0.02 | 0.015 | - | - | - |
| HC2601 | 0.08 | 1.2 | 0.10 | 0.02 | 0.015 | - | - | - |
| HC180Y | 0.01 | 0.8 | 0.08 | 0.025 | 0.010 | - | ≤ 0.12 | - |
| HC220Y | 0.01 | 1.4 | 0.10 | 0.025 | 0.010 | - | ≤ 0.12 | - |
| HC300B | 0.10 | 1.0 | 0.12 | 0.030 | 0.015 | 0.5 | - | - |
| HC260LA | 0.10 | 1.0 | 0.025 | 0.025 | 0.015 | 0.5 | 0.15 | - |
| HC340LA | 0.12 | 1.4 | 0.025 | 0.025 | 0.015 | 0.5 | 0.15 | 0.09 |
| HC420LA | 0.12 | 1.6 | 0.025 | 0.025 | 0.015 | 0.5 | 0.15 | 0.09 |
Gambar produk
