Ferit Stainless Steel Welded Tube AISI443, 304 Seamless Tubing Untuk Sistem Knalpot
Rincian produk
stainless tube steel
,diameter besar tabung baja stainless
Super Ferrite Stainless Steel Welded Tube AISI443 untuk sistem knalpot
Komponen kimia
| Bahan | C | Ya. | Mn | P | S | Cr | Tidak | Mo | Ti | Nb | N |
| 409L | 0.006 | 0.25 | 0.17 | 0.020 | 0.001 | 12.5 | - | - | 0.15 | 0.20 | 0.007 |
| 429 | 0.008 | 1.5 | 0.30 | 0.002 | 0.001 | 15.0 | - | - | 0.15 | 0.5 | 0.010 |
| 439 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 17.5 | - | - | 0.15 | 0.20 | 0.010 |
| 441 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 17.5 | - | - | 0.15 | 0.45 | 0.010 |
| 436L | 0.007 | 0.47 | 0.24 | 0.016 | 0.003 | 17.5 | 0.12 | 1.09 | 0.15 | 0.22 | 0.013 |
| 443 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 20.5 | - | - | 0.25 | 0.25 | 0.011 |
| 444 | 0.010 | 0.25 | 0.14 | 0.014 | 0.003 | 18.3 | 0.18 | 1.99 | 0.16 | 0.32 | 0.012 |
| 445 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 20.8 | - | - | 0.25 | 0.25 | 0.011 |
| 445J1 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 21.5 | - | 0.8 | 0.25 | 0.25 | 0.011 |
| 445J2 | 0.009 | 0.25 | 0.25 | 0.02 | 0.001 | 21.5 | - | 1.8 | 0.25 | 0.25 | 0.011 |
| 446 | 0.010 | 0.25 | 0.20 | 0.023 | 0.002 | 26.5 | 2.5 | 3.5 | 0.15 | 0.30 | 0.021 |
304 pipa baja tahan karat
Apa itu baja tahan karat SUPER FERRITE?
*Ini adalah jenis stainless steel ferrit yang mengandung karbon rendah, nitrogen dan unsur kimia lainnya.
*C+N≤120ppm -400ppm ((250ppm,150ppm).
Karakteristik
*Dengan karbon dan nitrogen yang sangat rendah - memenuhi persyaratan pengolahan dan kinerja
*Niobium titanium stabilisasi ganda-performance pengelasan yang ditingkatkan
* Kandungan kromium:kromium rendah ((10,5-15%), kromium ((15-22%) dan kromium tinggi ((22-32%);
Keuntungan
* Kemampuan korosi stres yang baik, semua jenis korosi lokal, korosi antioksidan (termasuk ketahanan oksidasi suhu tinggi).
*Densitas rendah
Konduktivitas termal yang baik: 30%-50% lebih tinggi dari austenit. Koefisien ekspansi termal kecil: 30%-40% lebih rendah dari austenit.
*Modul elastis besar
*Sifat pengolahan yang baik
* Mudah lentur, stamping, curling, pinin, cold forging dan machining.
*Kemampuan tarik yang sangat baik
Industri yang berlaku
Sistem knalpot:429, 436L, 439M,441
Dekoratif/produk:019Cr21Cu Ti ((443)
Sistem air:444,445J1/445J2
Ketahanan korosi yang tinggi:446
Toleransi Diameter Luar dan Ketebalan DindingSatuan: mm
| Penggulung panas (ekstrusi, ekspansi) tabung baja | Tabung baja yang ditarik dingin (rolling) | ||||||
| Dimensi | Toleransi | Dimensi | Toleransi | ||||
| PA Kelas Biasa | PC Tingkat Tinggi | PA Kelas Biasa | PC Tingkat Tinggi | ||||
| Diameter luar nominal D | 68 ~ 159 | ± 1,25%D | ± 1%D | Diameter luar nominal D | 6 ~ 10 | ± 0.20 | ± 0.15 |
| > 10 ~ 30 | ± 0.30 | ± 0.20 | |||||
| > 30 ~ 50 | ± 0.40 | ± 0.30 | |||||
| > 50 ~ 219 | ± 0,85%D | ± 0,75%D | |||||
| >159 | ±1,5%D | >219 | ± 0,9%D | ± 0,8%D | |||
| Ketebalan dinding nominal S | < 15 | +15%S - 12,5% | ± 12,5%S | Ketebalan dinding nominal S | ≤3 | ±12%S | ± 10%S |
| ≥ 15 | +20%S -15%S | >3 | + 12,5%S -10%S | ± 10%S | |||
Toleransi Ketebalan Tembok MinimalSatuan: mm
| Metode Produksi | Dimensi | Toleransi | |
| PA Kelas Biasa | PC Tingkat Tinggi | ||
| Penggulung panas (ekstrusi, ekspansi) tabung baja W-H | Smenit< 15 | +25%Smenit 0 | + 22,5%Smenit 0 |
| Smenit≥ 15 | +32,5%Smenit 0 | ||
| Tabung baja yang ditarik dingin (rolling) WC | Semua Kekakuan Dinding | +22%Smenit 0 | +20%Smenit 0 |
-
