A270 SUS304 76.2 * 2mm Cermin Polishing Stainless Steel Dilas Tabung Baja Presisi
Rincian produk
stainless steel putaran tabung
,diameter besar tabung baja stainless
A270 SUS304 76.2*2mm Mirror Polishing Stainless Steel Welded Precision Steel Tube
TEST:
100% PMI, Tes Anlisis Spektrokimia untuk bahan baku;100% Tes Hidrostatik atau 100% Tes NON-DESTRUKTIF;
Deskripsi:
Selesaikan:Anil & acar, brilian anil, dipoles
Kisaran ukuran untuk tabung:OD 1/4" sampai 80" (6mm sampai 2000mm),THk 0,02" sampai 2" (0,5mm sampai 50mm)
| Bahan: | TP321 SUS321 AISI321 UNS S32100 1.4541 X6CrNiTi18-10 08X18H10T, TP316/316L/316H, 304/304L/304H, 321/321H, 317/317L, 347/347H, 309S, 310S, 2205, 2507, 904L (1.4301, 1.4306, 1.4948, 1.4401, 1.4404, 1.4571, 1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845) |
| Standar: | ASTM A554,312, A249,A269, A270,A312,A358,A409,A778,A789, A790,A928, EN 10217, EN 10296,DIN 17456, DIN 17458, JISG3459, JIS G3463, JIS G3467, JIS G3448,JIS G3468 |
Nominal Dia:3/8 "untuk 80" NB untuk pipa las, Jadwal: 5S, 10S, 40S, 80S, 10, 20, 30...120, 140, 160, XXS
Semua dimensi sesuai dengan ANSI B36.19 dan ANSI B36.10
Panjangnya:20 m ((Max) atau sesuai kebutuhan Anda
Proses:EFW (Argon arc welding/TIG, plasma arc welding/PAW, dan submerged arc welding/SAW)
Kemasan:
1.Pengemasan kosong
2.Paket dengan kantong tenunan
3.Pengemasan kotak rangka kayu atau baja
4.Perlindungan tutup plastik di kedua sisi tabung
5.Dilindungi dengan baik untuk pengiriman laut atau sesuai permintaan.
6.Dibuat khusus
Akhir:Berujung berbeveled atau polos, potong persegi, bebas burr, Tutup plastik di kedua ujung
Aplikasi:Industri minyak bumi, kimia, pupuk, boiler dan aerospace, tenaga nuklir dan industri lainnya
-
