Tabung Baja Presisi Dingin ASTM A519 1020 Pipa Karbon Mulus
Rincian produk
Presisi pipa baja
,Pipa seamless presisi
2Kelas baja:SAE1010, SAE1020, SAE1026, SAE4130, SAE4140
6.Kelas dan Komposisi Kimia (%)
| Kelas | C | Mn | P≤ | S≤ | Ya. | Cr | Mo |
| 1008 | ≤ 0.10 | 0.30-0.50 | 0.040 | 0.050 | - | - | - |
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1025 | 0.22-0.28 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
7Sifat mekanik:
| Kelas | Kondisi | Titik tarik (Mpa) | Titik hasil (Mpa) | Perpanjangan |
| 1020 | CW | ≥ 414 | ≥ 483 | ≥ 5% |
|
| SR | ≥ 345 | ≥ 448 | ≥ 10% |
|
| A | ≥ 193 | ≥ 331 | ≥ 30% |
|
| N | ≥ 234 | ≥ 379 | ≥ 22% |
| 1025 | CW | ≥ 448 | ≥ 517 | ≥ 5% |
|
| SR | ≥ 379 | ≥ 483 | ≥ 8% |
|
| A | ≥ 207 | ≥ 365 | ≥ 25% |
|
| N | ≥ 248 | ≥ 379 | ≥ 22% |
| 4130 | SR | ≥ 586 | ≥ 724 | ≥ 10% |
|
| A | ≥ 379 | ≥ 517 | ≥ 30% |
|
| N | ≥ 414 | ≥ 621 | ≥ 20% |
| 4140 | SR | ≥ 689 | ≥ 855 | ≥ 10% |
|
| A | ≥ 414 | ≥ 552 | ≥ 25% |
|
| N | ≥ 621 | ≥ 855 | ≥ 20% |
9Memotong ke dalam kemasan panjang pendek:
10. FAQ
T: Apakah Anda perusahaan dagang atau produsen?
A: Penemu profesional pipa baja, produsen dan penyedia solusi
T: Berapa lama waktu pengiriman Anda?
A: Umumnya adalah 7-14 hari jika barang ada di stok. atau 30-60 hari jika barang tidak ada di stok, dan itu sesuai dengan kuantitas.
T: Apakah Anda menyediakan sampel? apakah itu gratis atau tambahan?
A: Ya, kami dapat menawarkan sampel gratis tetapi Anda perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A: Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, jangan ragu untuk menghubungi kami
-
