Tekanan Tinggi Karbon Ringan Tabung Baja Mulus Tebal Dinding Tebal Panjang 1-12m
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO 9001 ISO14001 TS16949
Nomor Model:
DIN 2391
Properti Perdagangan
Jumlah Pesanan Minimum:
5 ton
Harga:
900-1500 USD/ton
Ketentuan Pembayaran:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 Ton per Tahun
Ringkasan Produk
TORICH Seamless Carbon Light 300mm Diameter Besar ST37 15Mo3 Tekanan Tinggi 4 Inch C45 Heavy-caliber Heavy Thick Wall Steel Pipe Jangkauan ukuran: OD:20-300mm WT: 5-50mm Panjang: Max 12000mm Karakteristik: Toleransi OD dan ID yang baik dikontrol sesuai dengan standar teknis Kualitas stabil Toleransi...
Rincian produk
Menyoroti:
heavy wall steel pipe
,Tebal dinding Steel Tube
Characteristic:
Pipa Baja Dinding Tebal Berat
Material:
ST37, C45 dll
Production Method:
Ditarik Dingin
Package:
Dalam bundel atau sesuai permintaan
End Protector:
Polos / Miring
Length:
1-12m
Type:
Tabung Baja Presisi
MTC:
EN10204.3.1
Deskripsi Produk
TORICH Seamless Carbon Light 300mm Diameter Besar ST37 15Mo3 Tekanan Tinggi 4 Inch C45 Heavy-caliber Heavy Thick Wall Steel Pipe
Jangkauan ukuran:
OD:20-300mm
WT: 5-50mm
Panjang: Max 12000mm
Karakteristik:
Toleransi OD dan ID yang baik dikontrol sesuai dengan standar teknis
Kualitas stabil
Toleransi:
OD:
D 5 10 mm: ± 0,15 mm
D 11 30 mm: ± 0,30 mm
D 32 mm: ± 0,40 mm
D 51 140 mm: ± 0,8%
WT:
S 0,4 1 mm: ± 0,12 mm
S 1.2 5 mm: ± 10%
S 5.5 12 mm: ± 8%
Catatan:
1. kelas baja: 10, 20, 35, 45, 10Mn2, 15Cr, 20Cr, 40Cr, 30CrMnSi, 15CrMo sesuai dengan GOST 1050-88, GOST 19281-89, GOST 4543-71.
2. Dimensi dan toleransi sesuai dengan GOST 8734-75.
3. Persyaratan teknis sesuai dengan GOST 8733-74.
4Panjang dari 1,5 sampai 11,5 m tergantung pada diameter dan ketebalan dinding.
| Standar | Kelas baja | C | Ya. | Mn | P | S |
| EN 10305-1 | E215 | ≤ 0.10 | ≤ 0.05 | ≤ 0.70 | ≤ 0.025 | ≤ 0.025 |
| E235 | ≤ 0.17 | ≤ 0.35 | ≤ 1.20 | ≤ 0.025 | ≤ 0.025 | |
| E355 | ≤ 0.22 | ≤ 0.55 | ≤ 1.60 | ≤ 0.025 | ≤ 0.025 | |
| DIN 2391 | St35 | ≤ 0.17 | ≤ 0.35 | ≥ 0.40 | ≤ 0.025 | ≤ 0.025 |
| St37.4 | ≤ 0.17 | ≤ 0.35 | ≥ 0.40 | ≤ 0.025 | ≤ 0.025 | |
| St45 | ≤ 0.21 | ≤ 0.35 | ≥ 0.40 | ≤ 0.025 | ≤ 0.025 | |
| St52 | ≤ 0.22 | ≤ 0.55 | ≤ 1.60 | ≤ 0.025 | ≤ 0.025 | |
| GB/T 3639 | 10 | 0.07-0.13 | 0.17-0.37 | 0.35-0.65 | ≤ 0.030 | ≤ 0.030 |
| 20 | 0.17-0.23 | 0.17-0.37 | 0.35-0.65 | ≤ 0.030 | ≤ 0.030 | |
| 35 | 0.32-0.39 | 0.17-0.37 | 0.50-0.80 | ≤ 0.030 | ≤ 0.030 | |
| 45 | 0.42-0.50 | 0.17-0.37 | 0.50-0.80 | ≤ 0.030 | ≤ 0.030 | |
| Q345B | ≤ 0.20 | ≤ 0.50 | ≤ 1.70 | ≤ 0.030 | ≤ 0.030 |
Produksi tabung baja:
Uji arus eddy dan uji ultrasonik:
Kemasan:
