DIN 2391 ST52 Tabung Baja Mulus OD 5-420mm Untuk Silinder Pneumatik
Properti Dasar
Tempat Asal:
Zhejiang, China
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
DIN 2391, EN 10305-1, SAE J524, ASTM A519 dan GB3639
Properti Perdagangan
Jumlah Pesanan Minimum:
3 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
5000 TON PER BULAN
Ringkasan Produk
DIN 2391 ST52 Tube Steel Seamless OD 5-420mm Untuk Silinder Pneumatik Penggunaan Berlaku pada tekanan hidrolik, silinder pneumatik, tong pompa minyak, badan motor, poros transmisi, dll. Tabung yang diasah untuk silinder hidrolik Standar DIN2391, EN10305, JIS G3445, ASTM A519, GB/T 8713... Bahan ST45...
Rincian produk
Menyoroti:
Pipa baja mulus
,stainless steel presisi tubing
Product Name:
DIN 2391 ST52 Tabung Baja Mulus OD 5-420mm Untuk Silinder Pneumatik
Keyword:
ST52 Tabung Baja Seamless
Application:
Berlaku untuk tekanan hidrolik, silinder pneumatik, barel pompa minyak, badan motor, poros transmisi
Shape:
Bulat
Material:
ST52 ST52.3 E355 ST37 16Mn Q345B 1020
Delivery Condition:
BK
OD:
Too many requests
WT:
0.5-50mm
Length:
Max 12000mm
Brand:
UNTUK KAYA
Deskripsi Produk
DIN 2391 ST52 Tube Steel Seamless OD 5-420mm Untuk Silinder Pneumatik
Penggunaan
Berlaku pada tekanan hidrolik, silinder pneumatik, tong pompa minyak, badan motor, poros transmisi, dll.
| Tabung yang diasah untuk silinder hidrolik | ||
| Standar | DIN2391, EN10305, JIS G3445, ASTM A519, GB/T 8713... | |
| Bahan | ST45, ST52, E355, E355SR, STKM13C, SAE1026, 20#, Q235B, CK45... | |
| Pengolahan panas | BK+S | |
| Spesifikasi | Diameter luar ((mm) | Diameter dalam ((mm) |
| 50-300mm | 40-250 | |
| I.D Toleransi | H8-H9 | |
| Panjang | 3-9m (Pelanggan biasanya memilih 4 ~ 5.8m) | |
| Kejujuran | 1/1000 | |
| Kekerasan ID | RA 0,4mikron ((max) | |
| Teknologi | Dihiasi & SRB ((Skived & Roller Burnished)) | |
| Ruang lingkup | Tabung diasah untuk silinder hidrolik, derek berputar, mesin injeksi dan aplikasi mesin konstruksi | |
Proses
Bahan baku-Ditarik dingin/digulung-Perawatan panas ((BKS) - Diasah atau SRB- pengemasan
Kelas baja
ST52, ST52.3, E355, SAE1026, Q345B.
* Uji benturan suhu rendah atas permintaan (27J/-20°C).
Ukuran
Pengolahan Diameter silinderLength/mmStraightnessKetepatan ukuranKebalinan dinding/mmInner boreroughness
Ditarik dingin/DilapisiID28~OD400≤12M0.3~1.0m m/m H8-H11±5%0.8~1.6um
Diasah/SRBID30~OD500≤12M0.3~1.0m m/m H8±5%0.4~0.8um
Kemasan:Dengan minyak anti karat pada diameter dalam setiap pipa, tutup tabung di kedua ujung, bundel heksagonal maksimum 3.000 kg dengan beberapa strip baja, tas nilon dan bungkus kertas tahan air setiap bundel.pelanggan dapat menyesuaikan cara pengemasan lainnya.
