ASTM312 304 316 310s 2 "Tabung Stainless Steel Untuk Sistem Perpipaan
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO BV SGS
Nomor Model:
A270 A213 A312
Properti Perdagangan
Jumlah Pesanan Minimum:
0,5 TON
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C,, T / T
Kemampuan Penyediaan:
5000tons per tahun
Ringkasan Produk
ASTM312 304 316 310s 2" tabung baja tahan karat untuk sistem pipa Spesifikasi cepat: Bahan: 304 316 dll Standar:A270 A213 A312 Panjang: 12m max, sesuai dengan permintaan pelanggan, dapat dipotong menjadi pendek. Kisaran ukuran: OD 6-325mm WT 0,5-20mm Aplikasi: sistem pipa Permukaan: Penggorengan + ...
Rincian produk
Menyoroti:
stainless steel putaran tabung
,stainless tube steel
Material:
304,316 dll
Size:
6-325mm
Length:
maksimal 12m
Application:
sistem perpipaan
Surface:
pemolesan
End:
Polos
Certification:
ISO
Steel Grade:
300 Seri
Deskripsi Produk
ASTM312 304 316 310s 2" tabung baja tahan karat untuk sistem pipa
Spesifikasi cepat:
Bahan: 304 316 dll
Standar:A270 A213 A312
Panjang: 12m max, sesuai dengan permintaan pelanggan, dapat dipotong menjadi pendek.
Kisaran ukuran: OD 6-325mm WT 0,5-20mm
Aplikasi: sistem pipa
Permukaan: Penggorengan + penggilingan atau penggilingan atau polishing yang cerah.
Peralatan:
Mesin menggambar dingin
Penggaris
Tungku penggilingan
PenggorenganSatuan
Peralatan inspeksi:
Analis Spektrum Optik
Mesin eksperimen bahan universal
Perangkat Korosi Intergranular
Penguji dampak
Pengukur tekanan hidraulik
ECT
Detektor Kerapatan
Ect
Persyaratan Kimia
| | C | Ya. | Mn | P≤ | S≤ | Cr | Mo | Tidak | lainnya |
| 201 | ≤ 0.15 | ≤ 1.00 | 5.5-7.5 | 0.06 | 0.03 | 16-18 | - | 3.5-5.5 | N ≤ 0.25 |
| 202 | ≤ 0.15 | ≤ 1.00 | 7.5-10.0 | 0.06 | 0.03 | 17-19 | - | 4.0-6.0 | N ≤ 0.25 |
| 301 | ≤ 0.15 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 16-18 | - | 6.0-8.0 | - |
| 302 | ≤ 0.15 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 17-19 | - | 8-10.0 | - |
| 303 | ≤ 0.15 | ≤ 1.00 | ≤ 2.00 | 0.2 | ≥ 0.015 | 17-19 | ≤ 0.6 | 8.0-10.0 | - |
| 304 | ≤ 0.08 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 18-20 | - | 8-10.5 | - |
| 304L | ≤ 0.03 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 18-20 | - | 9-13 | - |
| 305 | ≤ 0.12 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 17-19 | - | 10.5-13 | - |
| 309S | ≤ 0.08 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 22-24 | - | 12-15 | - |
| 310S | ≤ 0.08 | ≤ 1.5 | ≤ 2.00 | 0.045 | 0.03 | 24-26 | - | 19-22 | - |
| 316 | ≤ 0.08 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 10-14 | - |
| 316L | ≤ 0.03 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 16-18 | 2-3 | 12-15 | - |
| 317 | ≤ 0.03 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
| 317L | ≤ 0.03 | ≤ 1.00 | ≤ 2.00 | 0.045 | 0.03 | 18-20 | 3-4 | 11-15 | - |
| 405 | ≤ 0.08 | ≤ 1.00 | ≤ 1.00 | 0.04 | 0.03 | 11.5-14.5 | - | ≤ 0.6 | AL0.1-0.3 |
Aplikasi:
