Tabung Baja Presisi untuk Pegas Gas dan Peredam Kejut
Rincian produk
pipa baja presisi
,pipa seamless presisi
Tabung baja presisi untuk gas spring dan shock absorber
Komposisi Kimia dan Sifat Mekanis:
| Besi kelas |
Komposisi kimia |
Sifat mekanik | ||||||
| C% | Si% | Mn% | P% | S% | Kekuatan tarik (Mpa) | Kekuatan hasil (Mpa) | Perpanjangan | |
| SPCC/SPHC | ≤ 0.12 | ≤ 0.025 | ≤ 0.50 | ≤ 0.035 | ≤ 0.025 | ≥ 270 | ... | ≥ 38 |
| ST12 ((DC01) | ≤ 0.10 | ... | ≤ 0.50 | ≤ 0.035 | ≤ 0.025 | ≥ 270 | 130-260 | ≥ 34 |
| ST37-2G/2 | ≤ 0.17 | ... | ≤ 1.00 | ≤ 0.035 | ≤ 0.030 | 360-510 | ≥215 | ≥ 20 |
| B340/590DP | ≤ 0.18 | ≤ 0.80 | ≤ 2.20 | ≤ 0.035 | ≤ 0.030 | ≥ 590 | 340 sampai 500 | ≥ 20 |
| B400/780DP | ≤ 0.20 | ≤ 0.80 | ≤ 2.50 | ≤ 0.035 | ≤ 0.030 | ≥ 780 | 400-590 | ≥ 16 |
| B340LA | ≤ 0.12 | ... | ≤ 1.00 | ≤ 0.030 | ≤ 0.030 | ≥440 | 240-460 | ≥26 |
| SS400 | ≤ 0.21 | ≤ 0.30 | ≤ 1.40 | ≤ 0.035 | ≤ 0.035 | 400-510 | ≥ 245 | ≥ 21 |
| Q195 | ≤ 0.12 | ≤ 0.30 | ≤ 0.50 | ≤ 0.035 | ≤ 0.040 | 315-430 | ≥195 | ≥33 |
| Q235B | 0.17-0.22 | ≤ 0.50 | ≤ 1.40 | ≤ 0.045 | ≤ 0.045 | 370-500 | ≥235 | ≥26 |
| Q345B | ≤ 0.20 | ≤ 0.30 | ≤ 1.70 | ≤ 0.035 | ≤ 0.035 | 470-630 | ≥ 345 | ≥ 20 |
| SAPH370 | ≤ 0.21 | ≤ 0.30 | ≤ 0.75 | ≤ 0.035 | ≤ 0.035 | ≥370 | ≥ 225 | ≥ 37 |
| SAPH400 | ≤ 0.21 | ≤ 0.30 | ≤ 1.20 | ≤ 0.030 | ≤ 0.025 | ≥ 400 | ≥255 | ≥ 36 |
| SAPH440 | ≤ 0.21 | ≤ 0.20 | ≤ 0.15 | ≤ 0.030 | ≤ 0.025 | ≥440 | ≥305 | ≥ 34 |
| Qste420TM | ≤ 0.12 | ≤ 0.50 | ≤ 1.50 | ≤ 0.030 | ≤ 0.025 | 480-620 | ≥420 | ≥ 21 |
| Qste460TM | ≤ 0.12 | ≤ 0.50 | ≤ 1.60 | ≤ 0.030 | ≤ 0.025 | 520-670 | ≥460 | ≥ 19 |
| BR1500HS/22MnB5 | 0.20-0.25 | 0.15-0.35 | 1.1-1.4 | ≤ 0.025 | ≤ 0.01 | 600 sampai 750 | ≥420 | ≥ 22 |
Tim teknis kami dapat membantu pada spesifikasi mata air gas Anda atau produk damper untuk memastikan bahwa
produk dipilih atau dikembangkan untuk aplikasi Anda.
Proses produksi:
Tabung seri DIN, tabung baja tanpa jahitan presisi yang ditarik dingin dan terang digunakan sebagai tabung yang akan difosfatkan.Fosforisasi dilakukan dengan cairan kimia yang diimpor untuk membentuk film hitamMinyak anti karat diserap melalui mikropor pada film untuk mencegah tabung menjadi berkarat.
Fitur Utama:
Warna hitam terang didistribusikan secara homogen pada permukaan tabung.
Aplikasi Utama:
Tabung hidraulik fosfat terutama digunakan dalam sistem hidraulik.
Produk kami banyak digunakan di:
Industri mesin Mesin alat mesin Industri hidrolik Kendaraan khusus
pipa mobil Mesin berat Kompresor Industri pembuatan kapal
Lokomotif kereta api Mesin Diesel Boiler Utilitas Mesin Injeksi
Peralatan listrik Mobil tugas berat Mesin penempaan dan pencetakan
Karakteristik utama:
Tidak ada lapisan oksidasi pada dinding luar dan dalam
Tidak ada retakan di bawah pembakaran dan perataan
Tidak ada kebocoran di bawah tekanan tinggi
Tidak ada distorsi setelah lentur dingin
Kejelasan Tinggi Kejernihan Tinggi Kecerahan yang sangat baik
-
