Boiler 195GH OD 420mm DIN17175 Pipa Baja Seamless
Properti Dasar
Tempat Asal:
Zhejiang, Cina
Nama merek:
TORICH
Sertifikasi:
ISO14001:2008,TS16949
Nomor Model:
EN10216-2 & DIN17175
Properti Perdagangan
Jumlah Pesanan Minimum:
5 Ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 Ton per tahun
Ringkasan Produk
EN10216-2& DIN17175 Pipa baja tanpa jahitan untuk tujuan tekanan - Ketentuan teknis pengiriman Aplikasi: Untuk pembuatan pipa boiler Peralatan kapal Jangkauan ukuran: O.D. 5-420mm W.T. 0.5-50mm Panjang max12000mm Kelas Baja, Komposisi Kimia dan Sifat Mekanis: Standar Kelas Komposisi Kimia Sifat ...
Rincian produk
Menyoroti:
DIN17175 Seamless Steel Pipe
,OD 420mm Seamless Steel Pipe
,195GH Seamless Steel Tube
Standard:
EN10216-2 & DIN17175
Application:
Untuk Pembuatan Pipa Boiler, Peralatan Kapal
Alloy Or Not:
Paduan
Technique:
Tertarik dingin
Secondary Or Not:
Non-sekunder
Grade:
195GH P235GH P265GH 20MnNb6 16Mo3 St35.8 St45.8 15Mo3
O.D.:
5-420mm
W.T.:
0,5-50mm
Length:
12000
Section Shape:
Bulat
Usage:
pipa ketel
Surface Treatment:
Mabuk
Deskripsi Produk
EN10216-2& DIN17175 Pipa baja tanpa jahitan untuk tujuan tekanan - Ketentuan teknis pengiriman
Aplikasi:
- Untuk pembuatan pipa boiler
- Peralatan kapal
Jangkauan ukuran:
| O.D. | 5-420mm |
| W.T. | 0.5-50mm |
| Panjang | max12000mm |
Kelas Baja, Komposisi Kimia dan Sifat Mekanis:
| Standar | Kelas | Komposisi Kimia | Sifat Mekanis | |||||||||
| C | Ya. | Mn | P | S | Cr | Mo | MPa | MPa | L | T | ||
| EN10216-2 | 195GH | ≤ 0.13 | ≤ 0.35 | ≤ 0.70 | ≤ 0.025 | ≤ 0.020 | ≤ 0.30 | ≤ 0.08 | 320-440 | ≥195 | ≥27 | ≥ 25 |
| P235GH | ≤ 0.16 | ≤ 0.35 | ≤ 1.20 | ≤ 0.025 | ≤ 0.020 | ≤ 0.30 | ≤ 0.08 | 360-500 | ≥235 | ≥ 25 | ≥ 21 | |
| P265GH | ≤ 0.20 | ≤ 0.40 | ≤ 1.40 | ≤ 0.025 | ≤ 0.020 | ≤ 0.30 | ≤ 0.08 | 410-570 | ≥265 | ≥23 | ≥ 20 | |
| 20MnNb6 | ≤ 0.22 | 0.15-0.35 | 1.00-1.50 | ≤ 0.025 | ≤ 0.020 | 500-650 | ≥355 | ≥ 22 | ≥ 20 | |||
| 16Mo3 | 0.12-0.20 | ≤ 0.35 | 0.40-0.90 | ≤ 0.025 | ≤ 0.020 | ≤ 0.30 | 0.25-0.35 | 450-600 | ≥ 280 | ≥ 22 | ≥ 20 | |
| DIN17175 | St35.8 | ≤ 0.17 | 0.10-0.35 | 0.40-0.80 | ≤ 0.030 | ≤ 0.030 | / | / | 360-480 | ≥235 | ≥ 25 | |
| St45.8 | ≤ 0.21 | 0.10-0.35 | 0.40-1.20 | ≤ 0.030 | ≤ 0.030 | / | / | 410-530 | ≥255 | ≥ 21 | ||
| 15Mo3 | 0.12-0.20 | 0.10-0.35 | 0.40-0.80 | ≤ 0.030 | ≤ 0.030 | / | 0.25-0.35 | 460-600 | ≥ 270 | ≥ 20 | ||
Tampilkan Produk
FAQ
Berapa jangka waktu pembayaranmu?
1.T/T: 30% deposit di muka, saldo 70% dibayarkan sebelum pengiriman
2.30% uang muka, saldo 70% dibayarkan terhadap L / C pada saat melihat
3Setelah negosiasi.
Siapa pelangganmu?
1Pemasok, Distributor, Penjual grosir, Agen, Pedagang, Pengguna Akhir, dll
Berapa lama kau akan bereaksi terhadap permintaan kami?
1.Permintaan Anda akan diproses dalam waktu 24 jam pada hari kerja. Kutipan akan dikirim setelah rincian teknis dikonfirmasi oleh pelanggan!
Jika ada pertanyaan tentang keraguan Anda, jangan ragu untuk mengirim email Anda atau hubungi kami!
