Incoloy 800 Incoloy 800h Incoloy 825 Tubing Inconel Pipe
Rincian produk
Incoloy 800h Tubing
,Inkolai 825 Tubing
,Inconel Pipe Tubing
Incoloy 800 Incoloy 800h Incoloy 825 Tubing Inconel Pipe
Incoloy 800 memiliki kekuatan pecah dan merangkak yang baik dan ketahanan yang sangat baik terhadap oksidasi,
suhu karburasi dan sulfidasi hingga 816°C.
Ini juga tahan korosi umum oleh banyak media berair.
Untuk aplikasi yang membutuhkan rupture tegangan yang lebih tinggi dan sifat merangkak,
terutama pada suhu di atas 816°C, Incoloy 800H dan 800HT dianjurkan.
Incoloy 800 mudah dibentuk, dilas dan diolah.
Informasi Dasar
Diameter luar:3.18mm-101.60mm
Ketebalan dinding:0.50mm-20.00mm
Panjangnya:Biasanya panjang tetap 6m, bisa sesuai dengan kebutuhan pelanggan
Standar:ASTM B163; ASTM B167; ASTM B444; ASTM B622 ect
Kelas material:
Alloy 800 / 800H / 800HT, Alloy 625/UNS N06625,
Alloy 600/UNS N06600, Alloy601/UNS N06601,
Alloy 800/UNS N08800, Alloy 825/UNS
N08825, Alloy400/UNS N04400; dll.
Aplikasi
Pipa proses kimia dan petrokimia
penukar panas
komponen tungku
peralatan karburasi,
lapisan elemen pemanas
dan tabung generator uap tenaga nuklir
Waktu Pengiriman
30 hari kerja setelah menerima deposit Anda (Biasanya sesuai dengan jumlah pesanan)
Tes
NTD ((Pengujian ultrasonik, uji Eddy Current)
Uji mekanik ((Uji ketegangan, Uji pembakaran, Uji perataan, Uji kekerasan, Uji hidrolik)
Tes logam ((Analisis metalografi, tes dampak suhu tinggi/rendah)
Analisis Kimia (Fotoelektrik Emisi Spektroskopis)
-
