ASTM A335 Feritik Alloy Steel Seamless Boiler Tubes
Properti Dasar
Tempat Asal:
Zhejiang, Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001; ISO14001; TSI16949
Nomor Model:
ASTM A335
Properti Perdagangan
Jumlah Pesanan Minimum:
5 Ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
60000 Ton per tahun
Ringkasan Produk
ASTM A335 Pipa Boiler Alloy Ferritic Steel Tanpa Jajar Untuk Layanan Suhu Tinggi Aplikasi:Untuk boiler, superheater, pipa uap boiler Teknik:Ditarik dingin Paduan atau tidak: Paduan Sekunder atau tidak: Non-Sekunder Kelas baja/bahan baja:P5 P9 P11 P12 P21 P22 P91 Jangkauan ukuran: O.D. 6-420mm W.T. 1...
Rincian produk
Menyoroti:
Feritik Alloy Seamless Boiler Tubes
,ASTM A335 Seamless Boiler Tubes
,ASTM A335 Boiler Tubes
Product Name:
ASTM A335 Pipa Boiler Baja Paduan Feritik Seamless Untuk Layanan Suhu Tinggi
Keyword:
Tabung Baja Karbon Seamless
Standard:
ASTM A335
Application:
Untuk Boiler, Superheater, Steam linepipes dari boiler
Alloy Or Not:
Paduan
Technique:
Tertarik dingin
Secondary Or Not:
Non-sekunder
Grade:
P5 P9 P11 P12 P21 P22 P91 P92
O.D.:
6-420mm
W.T.:
1-50mm
Length:
Sesuai dengan kebutuhan pelanggan
Section Shape:
Bulat
Usage:
pipa ketel
Surface Treatment:
Mabuk
Deskripsi Produk
ASTM A335 Pipa Boiler Alloy Ferritic Steel Tanpa Jajar Untuk Layanan Suhu Tinggi
Aplikasi:Untuk boiler, superheater, pipa uap boiler
Teknik:Ditarik dingin
Paduan atau tidak: Paduan
Sekunder atau tidak: Non-Sekunder
Kelas baja/bahan baja:P5 P9 P11 P12 P21 P22 P91
Jangkauan ukuran:
| O.D. | 6-420mm |
| W.T. | 1-50 mm |
| Panjang | maksimal 12000mm |
Karakteristik:
Konsentrisitas yang baik
Toleransi OD dan ID yang baik
Keakuratan Tinggi
Kualitas stabil
Kerontokan yang halus
TORICH Jaminan Kualitas
Komposisi Kimia:
| Kelas baja dan komposisi kimia: | |||||||
| Kelas baja | C | Mn | P | S | Ya. | Cr | Mo |
| maksimal | maksimal | maksimal | maksimal | maksimal | menit | ||
| P5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 4.00-6.00 | 0.45-0.65 |
| P9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 |
| P11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0 .65 |
| P12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
| P21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 2.65-3.35 | 0.80-1.06 |
| P22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
| P91 | 0.08-0.12 | 0.30-0.60 | 0.020 | 0.010 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 |
| P92 | 0.07-0.13 | 0.30-0.60 | 0.020 | 0.010 | 0.50 | 8.50-9.50 | 0.30-0.60 |
Proporsi mekanik:
| Kelas baja | Kekuatan tarik | Kekuatan Hasil | Perpanjangan | Kekerasan.Max. | ||
| Min.ksi [Mpa] | Min.ksi [Mpa] | % | Brinell/Vickers | Rockwell | ||
| P1, P2 | 55[380] | 30[205] | 20 | |||
| P12 | 60[415] | 32[220] | 20 | |||
| P23 | 74[510] | 58[400] | 20 | |||
| P91 | 85[585] | 60[415] | 30 | 250 HB/265 HV | 25 HRC | |
| P92, P911 | 90[620] | 64[440] | 30 | 250 HB/265 HV | 25 HRC | |
| P122 | 90[620] | 58[400] | 30 | 250 HB/265 HV | 25 HRC | |
Pameran Produk:
FAQ:
T: Apakah Anda perusahaan dagang atau produsen?
A: Penemu profesional pipa baja, produsen dan penyedia solusi
T: Berapa lama waktu pengiriman Anda?
A: Umumnya adalah 7-14 hari jika barang ada di stok. atau 30-60 hari jika barang tidak ada di stok, tergantung pada kuantitas.
T: Apakah Anda menyediakan sampel tabung baja tahan karat? apakah itu gratis atau tambahan?
A: Ya, kami bisa menawarkan sampel gratis tetapi perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A: Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, jangan ragu untuk menghubungi kami
