Tabung Inconel OD3.18mm 600718825601 mulus
Rincian produk
OD3.18mm Inconel 825 Tube
,OD3.18mm inconel 601 pipa
,OD3.18mm inconel 600 pipa
Inconel 600 718 825 Pipa tabung
ASTM B167Spesifikasi standar untuk paduan nikel-kromium-besi (UNS N06600,N06601,N06603,N06690,N06693,
N06025, N06045, dan N06696), paduan nikel-kromium-kobalt-molibdenum ((UNS N06617)), dan nikel-besi-kromium-tungsten
Alloy ((UNS N06674) Pipa dan Tabung Tanpa Jajar
Diameter luar:3.18mm-101.60mm
Ketebalan dinding:0.50mm-20.00mm
Panjangnya:Biasanya panjang tetap 6m, bisa sesuai dengan kebutuhan pelanggan
Standar:ASTM B163; ASTM B167; ASTM B444; ASTM B622 ect
Kelas material:
Alloy 800 / 800H / 800HT, Alloy 625/UNS N06625,
Alloy 600/UNS N06600, Alloy601/UNS N06601,
Alloy 800/UNS N08800, Alloy 825/UNS
N08825, Alloy400/UNS N04400; dll.
Aplikasi:
Pipa proses kimia dan petrokimia
penukar panas
komponen tungku
peralatan karburasi,
lapisan elemen pemanas
dan tabung generator uap tenaga nuklir
Waktu pengiriman:
30 hari kerja setelah menerima deposit Anda (Biasanya sesuai dengan jumlah pesanan)
Tes:
NTD ((Pengujian ultrasonik, uji Eddy Current)
Uji mekanik ((Uji ketegangan, Uji pembakaran, Uji perataan, Uji kekerasan, Uji hidrolik)
Tes logam ((Analisis metalografi, tes dampak suhu tinggi/rendah)
Analisis Kimia (Fotoelektrik Emisi Spektroskopis)
ASTM B167
Referensi standar ASTM:
B829 Spesifikasi untuk persyaratan umum untuk pipa dan tabung nirkabel dan paduan nikel
B880 Spesifikasi untuk persyaratan umum untuk batas analisis pemeriksaan kimia untuk Nikel, paduan Nikel dan paduan Kobalt.
E8 Metode pengujian untuk pengujian tegangan bahan logam.
E29 Praktek untuk menggunakan angka signifikan dalam data uji untuk menentukan kesesuaian dengan spesifikasi.
E38 Metode analisis kimia nikel-kromium dan paduan nikel-kromium-besi.
E112 Metode pengujian untuk menentukan ukuran butir rata-rata.
E527 Praktek penomoran logam dan paduan dalam sistem penomoran terpadu (UNS)
E1473 Metode pengujian untuk analisis kimia Nikel, Kobalt dan paduan suhu tinggi.
Kata kunci:pipa tanpa jahitan; tabung tanpa jahitan; UNS N06025; UNS N06045; UNS N06600; UNS N06601; UNS N06603;
UNS N06617; UNS N06674; UNS N06690; UNS N06693; UNS N06696
-
