Alloy 825 Austenitic Nickel-Iron-Chromium Alloy Steel Tubes
Rincian produk
Tabung baja paduan nikel-besi-kromium austenit
,Tabung baja paduan nikel-besi-kromium
,Tabung paduan 825
Paduan 825 Tabung paduan nikel-besi-kromium austenit
Deskripsi produk:
Akuncoloy 825adalah paduan austenit nikel-besi-kromium dengan penambahan molibdenum, tembaga dan titanium..Paduan ini tahan terhadap korosi tekanan klorida retak dan lubang. The addition of titanium stabilizes Alloy 825 against sensitization in the as-welded condition making the alloy resistant to intergranular attack after exposure to temperatures in a range that would sensitize unstabilized stainless steelsPembuatan Alloy 825 adalah khas dari paduan nikel-basis, dengan bahan yang mudah dibentuk dan dilas dengan berbagai teknik.
Alloy 825 KoilAlat dan peralatan mesin tugas berat digunakan untuk mengurangi pengerasan kerja paduan ini.Akunconel 825 Plat digunakan dalam industri minyak bumi untuk aplikasi seperti komponen sumur gas, katup dan tabung, serta menemukan penggunaan dalam sistem pipa kekuatan tinggi.Inconel 825 Lembarjuga digunakan dalam berbagai aplikasi industri seperti di Oil & Gas, Hangers, Tool Joints, Fasteners, Shafting dan banyak lagi.
Incoloy 825 Plat Kelas yang setara
| Standar | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | Keterangan: |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | EP703 | NFE30C20DUM | NiCr21Mo |
Komposisi Kimia
| Kelas | Tidak | C | Mn | Ya. | Cr | Fe | Al | Ti | Cu | S | |
| Incoloy 825 | MIN | 38.0 | ️ | ️ | ️ | 19.5 | 22.0 | ️ | 0.6 | 1.5 | ️ |
| Maksimal | 46.0 | 0.05 | 1.0 | 0.5 | 23.5 | ️ | 0.2 | 1.2 | 3.0 | 0.015 | |
Incoloy 825 Piring Sifat Fisik Mekanis
| Elemen | Kepadatan | Titik Peleburan | Kekuatan tarik | Kekuatan Hasil (0,2% Offset) | Perpanjangan |
| Incoloy 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi 80.000, MPa 550 | Psi 32,000, MPa 220 | 30 persen |
Aplikasi khas:
- Peralatan sumur minyak dan gas
- Sistem hidraulik
- Saluran injeksi kimia
- Peralatan dan wadah proses kimia
- Saluran kontrol lubang bawah
- Kontrol dan instrumentasi
- Produksi Asam
- Pengolahan bahan bakar nuklir
Gambar produk:
