Tabung Dilas Dingin Dilapisi
Rincian produk
Tabung yang digosok dingin
,tabung las yang ditarik dingin
,Tabung las yang ditarik dingin
Tabung las ditarik dingin berlapis
Tabung baja otomotif
TDW Tubing baja karbon rendah dinding berlapis ganda Tubing terutama untuk rem
TSW Selang baja rendah karbon Selang terutama untuk bahan bakar dan pelumasan
STKM 11J Tabung baja karbon untuk mesin Tujuan struktural Tabung untuk pendinginan dll
C1201 atau C1220 Tabung terutama untuk rem udara
Toleransi:
Dia eksternal: Nominal +/- 0,1 mm
Ketebalan dinding: Nominal +/- 0,1 mm
Penampilan: Tidak ada cacat berbahaya
Bahan tabung baja otomotif:
Komposisi Kimia:
| C | Mn | P | S |
| 0.12Max | 0.50Max | 0.04Max | 0.045Max |
Sifat mekanik
| T.S. | Y.P. | E.L. | HR30T |
| 30kg/mm2min | 18kg/mm2min | 25%min | 65Max |
Ketahanan Korosi (Jam)
| Zn8μm | Zn13μm | Zn25μm | Zn+PVF | |
| Putih | 72 | 72 | 72 | - |
| Merah | 192 | 288 | 480 | 3000 |
Uji tahan tekanan ((kg/mm2)
| DW | SW | |
| Di bawah 8 tahun | 350 | 250 |
| 8.00-10.0 | 250 | 200 |
Gambar produk:
Pengantar Perusahaan:
FAQ:
T: Apakah Anda perusahaan dagang atau produsen?
A: Kami adalah produsen pipa baja profesional.
T: Berapa lama waktu pengiriman Anda?
A: Umumnya dibutuhkan 7-14 hari jika barang ada di stok atau 30-60 hari jika tidak ada stok, ini terutama tergantung pada kuantitas.
Q: Apakah Anda menyediakan sampel gratis?
A: Ya,kami bisa menawarkan sampel gratis tetapi perlu membayar biaya pengiriman.
T: Apa syarat pembayaran Anda?
A:Pembayaran <=1000USD, 100% di muka. Pembayaran>=1000USD, 30% T / T di muka, saldo sebelum pengiriman.
Jika Anda memiliki pertanyaan lain, pls merasa bebas untuk menghubungi kami.
-
