ASTM A790 304 / 304L Duplex Stainless Steel Tube
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
ASTM A790
Properti Perdagangan
Jumlah Pesanan Minimum:
5 Ton
Harga:
Negoticable
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
500 ton per Bulan
Ringkasan Produk
ASTM A790 304 / 304L Duplex Stainless Steel Tube Nama produk: ASTM A790 304 / 304L Duplex Stainless Steel Tube Standar: ASTMA790 Bahan: SS201/301/302/321/304/304L/314/316/316L/310/310S/430 Duplex UNS S31803/S32205/S32750/S32760 dll. Jangkauan ukuran: OD:6mm - 630mm W.T.:0.5mm - 59.54mm Panjang: ...
Rincian produk
Menyoroti:
304 tabung stainless steel dupleks
,304L Duplex Stainless Steel Tube
Product Name:
ASTM A790 304 / 304L Duplex Stainless Steel Tube
Keyword:
pipa baja duplex
Type:
MUDAH DAN DILAS
Shape:
Bulat
Length:
Sesuai Permintaan Klien
Material:
SS201 / 301/302/321/304 / 304L / 314/316 / 316L / 310 / 310S / 430 Duplex UNS S31803 / S32205 / S327
Application:
Dekorasi, Konstruksi, Industri, Kimia, Pipa Fluida
End:
object(Yaf_Exception_LoadFailed_Controller)#14 (8) {
["string":"Exception":private]=>
string(0)
Deskripsi Produk
ASTM A790 304 / 304L Duplex Stainless Steel Tube
Nama produk: ASTM A790 304 / 304L Duplex Stainless Steel Tube
Standar: ASTMA790
Bahan: SS201/301/302/321/304/304L/314/316/316L/310/310S/430 Duplex UNS S31803/S32205/S32750/S32760 dll.
Jangkauan ukuran:
OD:6mm - 630mm
W.T.:0.5mm - 59.54mm
Panjang: Sesuai permintaan klien.
Aplikasi:Kerangka, Balustrade, Furnitur, Pagar, Dekorasi, Konstruksi, Industri Makanan, dll.
Komposisi kimia,%
| ASTM / UNS | C (max) | Si (max) | Mn (max) | P (max) | S (max) | Cr | Tidak | Mo | Ti |
| TP304 / S30400 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L / S30403 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-13.0 | ||
| TP304H / S30409 | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 8.0-11.0 | ||
| TP316 / S31600 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |
| TP316L / S31603 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP316Ti / S31635 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.7>5x(C+N) |
| TP321 / S32100 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
| TP317L / S31703 | 0.035 | 1.00 | 2.00 | 0.045 | 0.03 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 | |
| TP347H / S34709 | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-13.0 | ||
| TP309S / S30908 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 22.0-24.0 | 12.0-15.0 | 0.75 | |
| TP310S / S31008 | 0.080 | 1.00 | 2.00 | 0.045 | 0.03 | 24.0-26.0 | 19.0-22.0 | 0.75 |
