JIS G 3452 Pipa baja karbon untuk perpipaan biasa
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
IS09001 ISO14001 TS16949
Nomor Model:
JIS G 3452
Properti Perdagangan
Jumlah Pesanan Minimum:
2 ton
Harga:
1100USD/ton
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
JIS G 3452 Pipa baja karbon untuk pipa biasa Pipa hitam tanpa lapisan seng Pipa galvanis dengan lapisan seng Metode produksi: Kondisi pengiriman: Kelas baja:SGP Standar yang relevan: KS D 3507ASTM A 53API 5L DIN 2440 DIN 2441 BS 1387 BS 3601 JIS B 0203 JIS B 0253 JIS B 2301 Komposisi Kimia (%) Besi ...
Rincian produk
Menyoroti:
JIS G 3452 pipa baja karbon
,Pipa biasa Pipa baja karbon
Standard:
JIS G 3452
Material:
SDP
Size OD:
10.5-588mm
Length:
12m Max
Application:
perpipaan biasa
Place Of Origin:
Cina
Deskripsi Produk
JIS G 3452 Pipa baja karbon untuk pipa biasa
Pipa hitam tanpa lapisan seng
Pipa galvanis dengan lapisan seng
Metode produksi:
Kondisi pengiriman:
Kelas baja:SGP
Standar yang relevan: KS D 3507ASTM A 53API 5L DIN 2440 DIN 2441 BS 1387 BS 3601 JIS B 0203 JIS B 0253 JIS B 2301
| Komposisi Kimia (%) | ||
| Besi kelas | P | S |
| SGP | 0.040max | 0.040max |
| Properti Mekanis | ||
| Besi kelas | Kekuatan tarik Mpa | Elongasi% |
| SGP | 290 menit | 30 menit |
| Dimensi, Berat dan Toleransi Dimensi | |||||||
| Diameter nominal | OD ((mm) | Toleransi OD | WT mm | WT Toleransi | Massa satuan tidak termasuk soket kg/m | ||
| A | B | Pipa untuk dipotong dalam benang kerucut | Pipa lainnya | ||||
| 6 | 1/8 | 10.5 | ± 0,5 mm | ± 0,5 mm | 2.0 | +Tidak ditentukan - 12,5% | 0.419
|
| 8 | 1/4 | 13.8 | ± 0,5 mm | ± 0,5 mm | 2.3 | 0.652 | |
| 10 | 3/8 | 17.3 | ± 0,5 mm | ± 0,5 mm | 2.3 | 0.851 | |
| 15 | 1/2 | 21.7 | ± 0,5 mm | ± 0,5 mm | 2.8 | 1.31 | |
| 20 | 3/4 | 27.2 | ± 0,5 mm | ± 0,5 mm | 2.8 | 1.68 | |
| 25 | 1 | 34.0 | ± 0,5 mm | ± 0,5 mm | 3.2 | 2.43 | |
| 32 | 1 1/4 | 42.7 | ± 0,5 mm | ± 0,5 mm | 3.5 | 3.38 | |
| 40 | 1 1/2 | 48.6 | ± 0,5 mm | ± 0,5 mm | 3.5 | 3.89 | |
| 50 | 2 | 60.5 | ± 0,5 mm | ± 1% | 3.8 | 5.31 | |
| 65 | 2 1/2 | 76.3 | ± 0,7 mm | ± 1% | 4.2 | 7.47 | |
| 80 | 3 | 89.1 | ± 0,8 mm | ± 1% | 4.2 | 8.79 | |
| 90 | 3 1/2 | 101.6 | ± 0,8 mm | ± 1% | 4.2 | 10.1 | |
| 100 | 4 | 114.3 | ± 0,8 mm | ± 1% | 4.5 | 12.2 | |
| 125 | 5 | 139.8 | ± 0,8 mm | ± 1% | 4.5 | 15.0 | |
| 150 | 6 | 165.2 | ± 0,8 mm | ± 1,6 mm | 5.0 | 19.8 | |
| 175 | 7 | 190.7 | ± 0,9mm | ± 1,6 mm | 5.3 | 24.2 | |
| 200 | 8 | 216.3 | ±1,0mm | ± 0,8% | 5.8 | 30.1 | |
| 225 | 9 | 241.8 | ± 1,2 mm | ± 0,8% | 6.2 | 36.0 | |
| 250 | 10 | 267.4 | ± 1,3 mm | ± 0,8% | 6.6 | 42.4 | |
| 300 | 12 | 318.5 | ± 1,5 mm | ± 0,8% | 6.9 | 53.0 | |
| 350 | 14 | 355.6 | - | ± 0,8% | 7.9 | 67.7 | |
| 400 | 16 | 406.4 | - | ± 0,8% | 7.9 | 77.6 | |
| 450 | 18 | 457.2 | - | ± 0,8% | 7.9 | 87.5 | |
| 500 | 20 | 508.0 | - | ± 0,8% | 7.9 | 97.4 | |
