Cold Rolled Round Torich Diameter Besar Tabung Stainless Steel
Rincian produk
Tabung bundar baja tahan karat Torich
,Tabung Baja Tahan Karat Diameter Besar Torich
,Tabung Baja Tahan Karat Diameter Besar A312
TORICH ASTM A312 Besar Besar Diameter Industrial Stainless Steel Pipe dan Pipe
Ukuran
| Jenis jahitan | OD | WT |
| Jambatan tunggal | 6-914mm | 0.5-60mm |
| Tembaga ganda | 630-1524 mm | 2-80mm |
| Jambatan Bulat | lebih dari 630mm | 2-100mm |
Bahan yang Tersedia
| Bahan | Kelas |
| Baja tahan karat austenit | 310S, 309S, 316L, 321, 304, 304L |
| Duplex | S32750, S32760, S31803, S32205 |
| Paduan berbasis nikel | N08904, N06600, N08825 |
| Paduan Tembaga Nikel | C70600, C70620 |
| Ferrit | 430, 409L |
| Bahan Khusus Lain | 254SMO, 253MA |
| Bahan Temporasi Tinggi | 310S, 309S, S30815 |
| Paduan titanium | TA2, TA10, TC4 |
Kepadatan
| Kelas | ρ (kg/dm3) | Rumus Perhitungan | |
| 0Cr18Ni9 (06Cr19Ni10) SUS304 TP304 | 00Cr19Ni10 (022Cr19Ni10) SUS304L TP304L | 7.93 7.9 | W=0,02491 t(D-t) W=0,02482 t(D-t) |
| 0Cr17Ni12Mo2 SUS316 TP316 | 00Cr17Ni14Mo2 SUS316L TP316L | 8.0 | W=0,02513 t(D-t) |
Proses produksi pipa las jahitan lurus JCOE berdiameter besar:
Steel Coil→ Re-test→ Flat Open and Transverse Shear→ Shear (Longitudinal Shear)→ Perencanaan tepi dan penggilingan→
Pengelasan Butt of Plate→ Membentuk (Melengkung/Ruling)→ End Squaring&Tack Welding→ Pengelasan Jahit Pengelasan→
Pengelasan Otomatis→ Pengujian Radiografi→ Pengolahan Larutan→ Pengelompokan→ Perataan→ Pengolahan Menghadap Ujung→
Uji hidrostatik→ Passifasi pickling→ Cuci dan kering→ Uji radiografi→ Uji produk jadi→ Penandaan→
Pengemasan→ Pergudangan Produk Selesai→ Pengiriman
Aplikasi:
Tenaga listrik, penyulingan minyak, tenaga nuklir, air minum, teknik lepas pantai & pembuatan kapal, gas alam, pembuatan kertas, konstruksi
Gambar Produk
Pengantar Perusahaan
KONTROL KUALITAS
1. Inspeksi bahan baku yang masuk
2. Pengelompokan bahan baku untuk menghindari campuran kelas baja
3. Pemanasan dan Hammering End untuk Cold Drawing
4. Menggambar dingin dan penggulung dingin, pemeriksaan di jalur
5Pengolahan panas, +A, +SRA, +LC, +N, Q+T
6. Straightening-Motong ke panjang yang ditentukan-Selesai Pengukuran Inspeksi
7. Pengujian mekanik di laboratorium sendiri dengan kekuatan tarik, kekuatan hasil, elongasi, kekerasan, dampak, mikrostruktur dll
8Pengemasan dan Pengepakan
100% dari tabung baja kami diperiksa dimensi
100% tabung baja kami diperiksa secara visual untuk memastikan mereka memiliki kondisi permukaan yang sempurna dan tidak ada cacat permukaan.
Uji arus pusaran 100% dan uji ultrasonik untuk menghilangkan cacat longitudinal dan transversal
-
