SUS304 ASTM A312 TP 316L 600mm Tabung Baja Tahan Karat
Rincian produk
Tabung Stainless Steel ASTM A312
,Tabung Stainless Steel TP 316L
,Tabung Stainless Steel 600mm
06Cr19Ni10,SUS304ASTM A312 TP 316L Pipa Baja Ringan Berdiameter Besar 600mm ERW Pipa Baja Ringan / SS Tube
Detil cepat:
Bahan:06Cr19Ni10,SUS304,TP316L
Standar:ASTM A312
Ukuran: 600 mm
Nama Produksi:Pipa Baja Berkualitas Tinggi ERW Pipa Baja Berkualitas Tinggi/Pipa SS
Fitur: Diameter Besar
Bahan
| Bahan | |
| Baja tahan karat austenit | 310S, 309S, 316L,321,304L,304 |
| Duplex | S,32750,S32760,S31803,S32205 |
| Alloy berbasis nikel | N08904,N06600,N08825 |
| Paduan Tembaga Nikel | C70600,C70620 |
| Ferrit | 430,409L |
| Bahan Khusus Lain | 254SMO, 253MA |
| Bahan Temporasi Tinggi | 310S,309S,S30815 |
| Paduan titanium | TA2,TA10,TC4 |
Materi lain juga tersedia
06Cr19Ni10,SUS304ASTM A312 TP 316L Pipa Baja Ringan Berdiameter Besar 600mm ERW Pipa Baja Ringan / SS TubeTerutama berlaku diListrik
Pengolahan Minyak
Energi Nuklir
Air Minum
Offshore Engineering & Shipbuilding
Gas alam
Pembuatan kertas
Konstruksi
Tes:
Tes sinar-X
Dokumen:
MTC
Laporan tes sinar-X
Laporan uji ukuran
Laporan pengujian SGS jika diperlukan pemeriksaan pihak ketiga.
Berputar:
Steel Coil---Re-test---Flat Open dan Transverse Shear---Shear Longitudinal Shear---Pemetaan tepi dan penggilingan
Pengelasan ujung lempeng---Membentuk---Membengkokkan/Menggulingkan---Membentuk persegi ujung&Pengelasan tali---Membersihkan jahitan pengelasan
Pengelasan otomatis---Pengujian radiografi---Pengolahan larutan---Mengelinding---Menggaris
Pengolahan menghadap akhir---Hydrostatic Test--Pickling Passivation--Rush and Dry---Radiographic Test
Pengujian Produk Selesai---Penyirian---Pengemasan---Pergudangan Produk Selesai--Pengiriman
Kondisi pengiriman:
Pengolahan panas
Pemasangan
Pipa baja tahan karat ERW Pipa baja tahan karat/pipa SS Toleransi standar:
| Standar | Artikel | Diameter luar | Ketebalan | Kebulatan
| Kejujuran | Panjang | ||
| GB/T 12771 | Pengolahan panas | Kelas Tinggi | Umum | |||||
| < 50 | ± 0.20 | ± 0.3 | > 0,5-1.0, ± 0.15 > 1,0-2.0 ± 0.20 > 2,0-4.0 ± 0.3 ± 10% | Tidak melebihi toleransi OD t/D≤3% ≤1,5%D | OD ≤ 108 mm,≤ 1,5 mm/m > 108-325 mm ≤ 2,0 mm/m > 325mm ≤ 2,5 mm/m
| 3000-9000mm, Toleransi panjang adalah 0, + 20mm
| ||
| ≥40-<65 | ± 0.30 | ± 0.40 | ||||||
| ≥ 65-< 90 | ± 0.40 | ± 0.50 | ||||||
| ≥ 90-< 168.3 | ± 0.80 | ± 1.0 | ||||||
| > 168,3-< 325 | ± 0,75% D | ± 1% D | ||||||
| ≥325-<610 | ± 0,6% D | ± 1% D | ||||||
| > 610 | ± 0,6% D | ± 0,7% atau ± 10 Chose nilai min | ||||||
| Pemasangan | Semua ukuran | ± 0,5% D atau ± 0,20 memilih yang lebih besar | ± 0,75% D atau ± 0,30 memilih yang lebih besar | |||||
-
