1016mm JIS GS3468 304 Pipa Stainless Steel
Rincian produk
Pipa Stainless Steel 1016mm 304
,Pipa Stainless Steel JIS 304
,Pipa Stainless Steel GS3468 304
1016mm JIS GS3468 SUS 304 TPY dan 316TPY CNS 13517 Pipa stainless steel berdiameter besar ukuran SS 304
Detil cepat:
Ukuran 1016 mm kisaran ukuran dari 6-2000mm ketebalan dari 0.5-100mm
Membuat dengan jahitan tunggal doule jahitan lilitan ((Itu bisa membuat ukuran yang lebih besar)
Bahan: Baja tahan karat austenit,Duplex,Pengelasan Nikel-Basis,Pengelasan Tembaga Nikel,Ferrite,Baja Khusus Lainnya,Baja Temporatif Tinggi,Pengelasan Titanium
Kelas baja:
Duplex S,32750:
Duplex S,32750 Komposisi kimia:
Duplex ,S31803 Komposisi kimia
S32205 Komposisi kimia
Alloy berbasis nikel N08904 Komposisi kimia:
N06600 Komposisi kimia
N08825 Komposisi kimia
Proses produksi:
Koil baja
Uji ulang
Pemotong terbuka dan melintang datar
Gunting Gunting longitudinal
Perencanaan dan Penggilingan Tepi
Pengelasan plat but
Membentuk ((Mengelilingi/Mengguling)
End Square&Tack Welding
Pembersihan jahitan las
Pengelasan otomatis
Tes radiografi
Pengobatan dengan larutan
Pengelompokan
Perataan
Menghadapi Pengobatan Akhir
Uji hidrostatik
Passifikasi Penggorengan
Cuci dan keringkan
Tes radiografi
Pengujian Produksi Selesai
Penandaan
Pengemasan
Penyimpanan Produk Selesai
Pengangkutan
Standar:
GB/T 12771
Kondisi pengiriman:
Pengolahan panas
Pemasangan
| Standar | Artikel | Diameter luar | Ketebalan | Kebulatan
| Kejujuran | Panjang | ||
| GB/T 12771 | Pengolahan panas | Kelas Tinggi | Umum | |||||
| < 50 | ± 0.20 | ± 0.3 | > 0,5-1.0, ± 0.15 > 1,0-2.0 ± 0.20 > 2,0-4.0 ± 0.3 ± 10% | Tidak melebihi toleransi OD t/D≤3% ≤1,5%D | OD ≤ 108 mm,≤ 1,5 mm/m > 108-325 mm ≤ 2,0 mm/m > 325mm ≤ 2,5 mm/m
| 3000-9000mm, Toleransi panjang adalah 0, + 20mm
| ||
| ≥40-<65 | ± 0.30 | ± 0.40 | ||||||
| ≥ 65-< 90 | ± 0.40 | ± 0.50 | ||||||
| ≥ 90-< 168.3 | ± 0.80 | ± 1.0 | ||||||
| > 168,3-< 325 | ± 0,75% D | ± 1% D | ||||||
| ≥325-<610 | ± 0,6% D | ± 1% D | ||||||
| > 610 | ± 0,6% D | ± 0,7% atau ± 10 Chose nilai min | ||||||
| Pemasangan | Semua ukuran | ± 0,5% D atau ± 0,20 memilih yang lebih besar | ± 0,75% D atau ± 0,30 memilih yang lebih besar | |||||
-
