S45C 304300mm Tabung Silinder Hidraulik
Properti Dasar
Tempat Asal:
ZHEJIANG CHINA
Nama merek:
TORICH
Sertifikasi:
ISO 9001
Nomor Model:
DIN CK45
Properti Perdagangan
Jumlah Pesanan Minimum:
1 TON
Harga:
USD 1500-2000 Per Ton
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union,
Kemampuan Penyediaan:
500 ton per Bulan
Ringkasan Produk
S45C 304 SYLINDER HIDRAULIK STRONG PISTON PLATED CHROME keras Deskripsi proses manufaktur utama: 1. Pengurangan bahan baku baja hidrolik 2. CNC Machining + Kerongkongan Machining 3. Induksi pengerasan 4. Plating Chrome 5. Dehidrogenasi dan Tempering 6. Polandia dan Superfinish Polandia 7. 100% ...
Rincian produk
Menyoroti:
304 Tabung Silinder Hidraulik
,Tabung Silinder Hidraulik S45C
,Tabung Silinder Hidraulik 300mm
Size:
12-300mm
Material:
20 #, 45 #, 40Cr, 46CrMo4 atau sesuai kebutuhan
Technique:
tenggelam / terkelupas dingin
Tolerance:
ISO f7
Chrome Layer Thickness:
15-30μm
Leeb Hardness:
20-60HRC
Application:
tabung silinder
Roughness:
Ra ≤0.2u
Straightness:
≤ 0,2 / 1000
Length:
maks 16m
Deskripsi Produk
S45C 304 SYLINDER HIDRAULIK STRONG PISTON PLATED CHROME keras
Deskripsi proses manufaktur utama:
1. Pengurangan bahan baku baja hidrolik
2. CNC Machining + Kerongkongan Machining
3. Induksi pengerasan
4. Plating Chrome
5. Dehidrogenasi dan Tempering
6. Polandia dan Superfinish Polandia
7. 100% Pemeriksaan
8Kothak Kerajinan dan Kemasan Kasus Kayu
| Dimensi | φ6-250mm |
| Kelas | CK45 Hydraulic Hard Chrome Plated Piston Rod |
| Warna | Warna Alam |
| Toleransi | ISOf7/Syarat yang disesuaikan |
| Kebulatan | ≤ 1/2 Toleransi Diameter |
| Panjang standar | <φ30mm, 2-3meters/On Permintaan Panjang Potong ≥φ30mm,3-6meters/On Permintaan Panjang Potong Persyaratan yang disesuaikan |
| Keropositas permukaan | Ra≤0.2 |
| Ketebalan lapisan krom | <φ20mm:min15μm ≥φ20mm:min:20μm |
| Kekerasan lapisan krom | HV850 ~ HV1050 |
| Kejujuran | 0.15/1000mm |
| Uji Korosi Evaluasi | ISO 10289:1999,IDT |
| Kondisi Pengiriman | Normal, Q+T, INDUKSI KERAS |
| Keuntungan | Kami memeriksa setiap produk sebelum kemasan dan kami memberikan harga yang wajar |
