316 Stainless DIN2462 ISO14001 Tabung Baja Presisi
Rincian produk
Tabung Torich
,Tabung Baja Presisi DIN2462
,Tabung Baja Presisi ISO14001
304,316 NIKKEL NI STAINLESS STEEL (SS) CYLINDRICAL SPUTTERING Target,ROTARY TARGETS (TARGETS yang berputar)
Detil cepat:
| Bahan | 304L |
| Spesifikasi | 132.8-133.5mm |
| Toleransi | 132.8-133.5mm |
Kelas 304L
Spesifikasi: 133*4*4113mm
Toleransi OD:132.8-133.5mm
Toleransi ID:124.5-125.2mm
Toleransi Panjang:-0/+5mm
Ellipticity: Penyimpangan bulat ≤0,10mm
Penyimpangan tegak lurus: arah panjang keseluruhan≤0,5mm
Standar:DIN2462
Persyaratan Khusus:
- Persyaratan kualitas:
Toleransi OD:132.8-133.5mm
Toleransi ID:124.5-125.2mm Toleransi Panjang:-0/+5mm
Ellipticity: Penyimpangan bulat ≤0,10mm
Penyimpangan tegak lurus: arah panjang keseluruhan≤0,5mm
- Persyaratan penampilan:
Permukaan dalam dan luar pipa baja harus bebas dari retakan, kerang dan deformasi yang terlihat akibat pukulan busur, dan keruwetan permukaan Ra<32um.
Ujung luar harus bebas dari deformasi, cetakan elips dan cacat lainnya, dan badan pipa harus bebas dari lubang ((lubang lebih dari 0,1 mm tidak diizinkan pada dinding dalam pipa baja),Tidak ada goresan (0,1mm).
Kotoran pada lubang bagian dalam: tidak boleh ada pencemaran minyak di dalam dan di luar pipa baja atau kotoran dan karat yang tidak dapat dihilangkan dengan kertas pasir halus.
- Persyaratan kemasan:
Tutup casing di kedua ujung pipa baja, kemasan kantong tenun
- Persyaratan untuk huruf:
TP304L 138mm*4.4mm HEAT NO:×××
Catatan: ((Ukuran hanya digunakan cetak inkjet, ukuran cetak inkjet juga harus ditulis pada kemasan luar, bukan panjangnya)
Aplikasi:
Target Sputtering Planar,
Target Sputtering Alloy
Target Sputtering paduan Ag silinder
Kristal tunggal logam
-
