ASTM A269 316Ti Seamless Stainless Steel Welded Pipe Coil Shape
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
IS09001 ISO14001 TS16949
Nomor Model:
A269 A268 A249
Properti Perdagangan
Jumlah Pesanan Minimum:
0,5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, T / T
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
OD 1/16" sampai 3/4" WT 0,010" sampai 0,083" 321H 304 316 316Ti Seamless Welded Coil stainless steel tube coiling Detil cepat: Nama produk: OD 1/16" sampai 3/4" WT 0,010" sampai 0,083" 321H 304 316 316Ti Seamless Welded Coil stainless steel tube coiling OD:1/16 "untuk 3/4" WT:0.010" sampai 0.083" ...
Rincian produk
Menyoroti:
ASTM A269 Stainless Steel Welded Pipe
,316Ti Stainless Steel Welded Pipe
,Seamless Stainless Steel Tubing Coil
Material:
Besi tahan karat
Shape:
Round dan Coil
Length:
150m atau lainnya
Delivery Condition:
Anil cerah
Deskripsi Produk
OD 1/16" sampai 3/4" WT 0,010" sampai 0,083" 321H 304 316 316Ti Seamless Welded Coil stainless steel tube coiling
Detil cepat:
Nama produk:
OD 1/16" sampai 3/4" WT 0,010" sampai 0,083" 321H 304 316 316Ti Seamless Welded Coil stainless steel tube coiling
OD:1/16 "untuk 3/4"
WT:0.010" sampai 0.083"
Bahan:Baja tahan karat
Kelas baja: 321H 304 316 316Ti
Materi khusus lainnya juga tersedia.
Fitur:
Bahan baku berasal dari pabrik besar, seperti Baosteel, TISCO, POSO.
Lokakarya bersih
Keakuratan tinggi
Kekuatan Tinggi
Toleransi menurut standar ASTM A269:
| Diameter luar | Ketebalan | Panjang |
| < 38,1 ± 0,13 mm | OD ≤ 12.7 ± 15% OD ≥ 12.7 ± 10% | OD < 38.1 ± 3.2 OD ≥ 38.1 ±4,8-0 |
| ≥ 38,1 ~ 88,9mm±0.25 |
Toleransi menurut standar ASTM A 249:
| Diameter luar | Ketebalan | Panjang | |
| < 25.4 | ± 0.10 | ± 10% | OD < 50.8 ±3,0-0 |
| ≥ 25.4 ~ 38.1 | ± 0.15 | OD ≥ 50.8 ± 5,0-0 | |
Aplikasi:
Saluran kontrol minyak dan gas
Saluran injeksi kimia
Di bawah laut dan katup
Baterai pengolahan bahan kimia
Transfer cairan dan gas.
Aplikasi Arsitektur
Jarum Hipodermal
Industri otomotif
Industri makanan dan minuman
Industri Kelautan
Industri farmasi
Metode produksi:Menggambar dingin atau digulung dingin +Penggilingan terang
