A213 Bright Annealed 304 Stainless Steel Tubing Anti Korosi
Properti Dasar
Tempat Asal:
Cina
Nama merek:
Torich
Sertifikasi:
IS09001 ISO14001 TS16949
Nomor Model:
A269 A268 A249
Properti Perdagangan
Jumlah Pesanan Minimum:
0,5 ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
L / C, T / T
Kemampuan Penyediaan:
5000 ton per tahun
Ringkasan Produk
A213 A269 SS316/316L AP Pipe, MP Pipe, BA Pipe Round Tabung AP ((Annealed&Pickled) tabung MP ((Mechanical Polished) tabung BA ((Bright Annealed) Permukaan yang sangat halus di luar dan di dalam Keamatan Internasional yang sangat baik sesuai dengan keadaan teknologi Berkualitas tinggi untuk ketahanan ...
Rincian produk
Menyoroti:
A213 304 Stainless Steel Tubing
,Bright Annealed 304 stainless steel tubing
,Ss Seamless Pipe Tahan Korosi
Material:
Besi tahan karat
Shape:
Round dan Coil
Length:
150m atau lainnya
Delivery Condition:
Anil cerah
Deskripsi Produk
A213 A269 SS316/316L AP Pipe, MP Pipe, BA Pipe Round
Tabung AP ((Annealed&Pickled) tabung MP ((Mechanical Polished) tabung BA ((Bright Annealed)
Permukaan yang sangat halus di luar dan di dalam
Keamatan Internasional yang sangat baik sesuai dengan keadaan teknologi
Berkualitas tinggi untuk ketahanan korosi yang luar biasa
Pengaman yang tepat untuk tabung yang tepat
Bahan:304 316
Standar:A213 A269
Komposisi kimia:
SUS304 C≤0,08 Si≤1,00 Mn≤2,00 P≤0,05S ≤0,03 Cr18.00-20.00 Ni 8,00~10.50
316 C≤0,08Si≤1,00Mn≤2,00P≤0,035S≤0,03Ni:10.0-14.0Cr:16.0-18.5 Mo:2.0-3.0
Pengujian:
Komponen kimia
Analisis Inklusi normal
Uji Sifat Mekanis
UT
Pemeriksaan Penampilan dan Dimensi
Tabung BA
| OD | WT | Toleransi | Toleransi WT | Ketidakseimbangan |
| 6.35 | 1 | ± 0.07 | ± 10% | Rmax 3,0 μm |
| 9.53 | 1 | ± 0.07 | ||
| 12.7 | 1 | ± 0.1 | ||
| 12.7 | 1.24 | ± 0.1 | ||
| 15.88 | 1.24 | ± 0.1 | ||
| 19.05 | 1.24 | ± 0.12 | Rmax 4,0 μm | |
| 19.05 | 1.24 | ± 0.12 | ||
| 25.4 | 1.65 | ± 0.12 |
