Tabung Presisi 6M Ditarik Dingin Untuk Sistem Hidraulik Dan Pneumatik
Properti Dasar
Tempat Asal:
ZHEJIANG CHINA
Nama merek:
TORICH
Sertifikasi:
ISO 9001
Nomor Model:
EN10305-4
Properti Perdagangan
Jumlah Pesanan Minimum:
0,5 Ton
Harga:
USD 1200-1500 Per Ton
Ketentuan Pembayaran:
L / C, D / A, D / P, T / T, Western Union, MoneyGram
Kemampuan Penyediaan:
500 ton per Bulan
Ringkasan Produk
Tabung baja presisi yang ditarik dingin EN10305-4 E235 (((E255 E355) + NBK Untuk sistem hidrolik dan pneumatik ★Ketepatan tinggi dan tekanan tinggi, permukaan halus★Tidak ada tetes lapisan seng saat membengkok★Kekuatan anti korosi dan karat yang kuat ketika dipassifkan dalam lapisan seng Kualitas ...
Rincian produk
Menyoroti:
Tabung presisi 6M
,pipa baja presisi 6m
,tabung presisi TORICH
Standard:
ASTM, DIN, GB, JIS
Grade:
45 #, 20 #, 10 #
Thickness:
0,1 mm-60 mm, 0,3-3,5 mm, 1 - 8 mm
Outer Diameter:
0,4-20 mm
Length:
6 jt atau sebagai persyaratan
Section Shape:
Bulat
Alloy Or Not:
Non-Paduan
Technique:
Dingin Diambil, Cold Rolled
Surface Treatment:
Galvanis, customerized
Type:
tabung dilas atau mulus
Deskripsi Produk
Tabung baja presisi yang ditarik dingin EN10305-4 E235 (((E255 E355) + NBK Untuk sistem hidrolik dan pneumatik
★Ketepatan tinggi dan tekanan tinggi, permukaan halus
★Tidak ada tetes lapisan seng saat membengkok
★Kekuatan anti korosi dan karat yang kuat ketika dipassifkan dalam lapisan seng
Kualitas permukaan:
Tanpa oksidasi
Tidak ada retakan
Tidak ada lipatan
Tidak ada lipatan rolling
Tidak ada bekas luka.
Tidak ada cacat laminar
|
ODmm
| WT mm |
| 4 | 1 |
| 5 | 1 |
| 6 | 1 |
| 6 | 1.5 |
| 8 | 1 |
| 8 | 1.5 |
| 10 | 1 |
| 10 | 1.5 |
| 10 | 2 |
| 10 | 2.5 |
| 12 | 1 |
| 12 | 1.5 |
| 12 | 2 |
| 12 | 2.5 |
| 12 | 3 |
| 12.7 | 1.63 |
| 14 | 1 |
| 14 | 1.5 |
| 14 | 2 |
| 14 | 2.5 |
| 14 | 3 |
| 15 | 1 |
| 15 | 1.5 |
| 15 | 2 |
| 15 | 2.5 |
| 15 | 3 |
| 15.88 | 1.63 |
| 15.88 | 2.03 |
| 16 | 1 |
| 16 | 1.5 |
| 16 | 2 |
| 16 | 2.5 |
| 16 | 3 |
|
Lebih banyak ukuran yang tersedia, pls email saya untuk rincian.
| |
Aplikasi:
Sistem hidraulik
Mobil
