Tekanan tinggi bebas krom (bebas CR6) Tabung Baja Seamless Oli Hidrolik Din2391 En10305-4
Rincian produk
Tabung Baja Hidraulik Oli Seamless
,Tabung Baja Seamless Din2391
,Tabung Baja Seamless En10305-4
Minyak hidraulik baja tahan kerutan bebas kromium (CR6) tekanan tinggi
Torich adalah produsen tabung logam presisi selama lebih dari 20 tahun.
adalah produk panas kami,terutama diekspor ke Uni Eropa,AS Asia dll
Standar dari Seamless Steel Hydraulic Oil Tubing:DIN 2391 EN 10304-1/EN10305-4 DIN1629 DIN 1630
Bahan:ST52 ST37 ST44 ST52 ST37.4 ST44.4 ST52.4 ST35 ST45 ST52 E235 E355 dll.
Fitur utama dari Seamless Steel Hydraulic Oil Tubing:
Keakuratan tinggi
Kecerahan yang sangat baik
Tidak ada oksidasi pada dinding luar dan dalam setelah perawatan panas
Kebersihan dinding dalam yang tinggi
Tekanan tinggi
Tidak ada deformasi setelah lentur gumpalan
Tidak ada retakan setelah membakar dan meratakan
Kondisi pengiriman Pembuatan pipa minyak hidraulik baja tanpa jahitan:
BK,BKW,BKS,NBK dll.
Ukuran:OD:1.5-60mm ((0.1 inci-2 inci)
Ketebalan dinding:0.3-10mm ((0.012-0.35 inci)
Daftar ukuran utama:
| Diameter luar | Ketebalan dinding Imperial | Metrik Ketebalan Dinding |
|---|---|---|
| 6.35mm / 0.250 " | 20swg | 0.90mm |
| 6.35mm / 0.250 " | 18swg | 1.20mm |
| 6.35mm / 0.250 " | 16swg | 1.60mm |
| 6.35mm / 0.250 " | 14swg | 2.03mm |
| 7.94mm / 0.313 " | 20swg | 0.90mm |
| 7.94mm / 0.313 " | 18swg | 1.20mm |
| 7.94mm / 0.313 " | 16swg | 1.60mm |
| 7.94mm / 0.313 " | 14swg | 2.03mm |
| 9.53mm / 0.375 " | 20swg | 0.90mm |
| 9.53mm / 0.375 " | 18swg | 1.20mm |
| 9.53mm / 0.375 " | 16swg | 1.60mm |
| 9.53mm / 0.375 " | 14swg | 2.03mm |
| 9.53mm / 0.375 " | 12swg | 2.64mm |
| 9.53mm / 0.375 " | 11swg | 2.95mm |
| 9.53mm / 0.375 " | 10swg | 3.20mm |
| 11.11mm / 0.437 " | 20swg | 0.90mm |
| 11.11mm / 0.437 " | 18swg | 1.20mm |
| 11.11mm / 0.437 " | 16swg | 1.60mm |
| 11.11mm / 0.437 " | 14swg | 2.03mm |
| 11.11mm / 0.437 " | 12swg | 2.64mm |
| 11.11mm / 0.437 " | 11swg | 2.95mm |
| 11.11mm / 0.437 " | 10swg | 3.20mm |
| 12.70mm / 0,500 " | 20swg | 0.90mm |
| 12.70mm / 0,500 " | 18swg | 1.20mm |
| 12.70mm / 0,500 " | 16swg | 1.60mm |
Aplikasi pipa baja presisi:
Penggunaan utama: pipa baja tanpa jahitan minyak hidrolik untuk sistem hidrolik, pipa baja untuk mobil, dan pelanggan lain yang memiliki,
persyaratan tinggi untuk akurasi pipa baja, kelancaran, kebersihan, dan sifat mekanik.
Sistem hidraulik
Mobil
Sertifikat:EN 10204.3.1
Item Pemeriksaan:
Analisis kimia
Uji Arus Eddy 100% Ukuran dan permukaan mengikis 100%
Daftar inspeksi dan uji untuk DIN 2391 Standard Hydraulic Oil Seamless Steel Tubing
| Jenis pemeriksaan atau pengujian tabung baja presisi tanpa jahitan | Frekuensi pengujian | |
| Uji internal | Tes penerimaan | |
| Analisis kimia | M | M |
| Pengujian ketegangan | M | Satu per batch yang diuji |
| Uji perataan atau uji perpanjangan | M | Dua per batch yang diuji |
| Verifikasi dimensi | M | M |
| Pemeriksaan visual | M | M |
| NDT untuk mengidentifikasi kebocoran | Individual | Individual |
-
