Cold Drawn OSmooth Roughnes Seamless Steel Pipe GCr15 100Cr6
Properti Dasar
Tempat Asal:
Zhejiang, Cina
Nama merek:
TORICH
Sertifikasi:
ISO9001 ISO14001 TS16949
Nomor Model:
ISO683-17
Properti Perdagangan
Jumlah Pesanan Minimum:
5 Ton
Harga:
Dapat dinegosiasikan
Ketentuan Pembayaran:
T / T, L / C, D / A, D / P, Western Union, MoneyGram
Kemampuan Penyediaan:
50.000 ton per tahun
Ringkasan Produk
GCr15 100Cr6 OD85XWT11.5 tabung baja tanpa jahitan Kelas baja/bahan baja: Kelas baja pecahan massa % C Ya. Mn P S Cr Mo GCr15 0.95-1.05 0.15-0.35 0.20-0.40 ≤ 0.027 ≤ 0.020 1.30-1.65 ≤ 0.10 100Cr6 0.93-1.05 0.15-0.35 0.25-0.45 ≤ 0.025 ≤ 0.015 1.35-1.60 ≤ 0.10 100CrMnSi6-4 0.93-1.05 0.45-0.75 1.00-1...
Rincian produk
Menyoroti:
Pipa Baja Seamless Dingin Yang Ditarik
,Pipa Baja Seamless 100Cr6
,Pipa Baja Seamless Kekasaran Halus
Product Name:
GCr15 100Cr6 OD85XWT11.5 Tabung Baja Seamless
Application:
untuk bantalan otomotif
Shape:
Bulat
Type:
Dingin Diambil
Keyword:
Tabung bantalan
Material:
100Cr6, GCr15
Surface:
Disesuaikan
Length:
1-12000mm
OD:
10-260mm
WT:
2-30mm
Deskripsi Produk
GCr15 100Cr6 OD85XWT11.5 tabung baja tanpa jahitan
Kelas baja/bahan baja:
| Kelas baja | pecahan massa % | ||||||
| C | Ya. | Mn | P | S | Cr | Mo | |
| GCr15 | 0.95-1.05 | 0.15-0.35 | 0.20-0.40 | ≤ 0.027 | ≤ 0.020 | 1.30-1.65 | ≤ 0.10 |
| 100Cr6 | 0.93-1.05 | 0.15-0.35 | 0.25-0.45 | ≤ 0.025 | ≤ 0.015 | 1.35-1.60 | ≤ 0.10 |
| 100CrMnSi6-4 | 0.93-1.05 | 0.45-0.75 | 1.00-1.20 | ≤ 0.025 | ≤ 0.015 | 1.40-1.65 | ≤ 0.10 |
| 100CrMnSi6-6 | 0.93-1.05 | 0.45-0.75 | 1.40-1.70 | ≤ 0.025 | ≤ 0.015 | 1.40-1.65 | ≤ 0.10 |
| 100CrMo7 | 0.93-1.05 | 0.15-0.45 | 0.25-0.45 | ≤ 0.025 | ≤ 0.015 | 1.65-1.95 | 0.15-0.30 |
Kondisi pengiriman:+C, +LC, +SR, +A, +N
Jangkauan ukuran:
OD: 10-260mm
WT: 2-30mm
Panjang: 2-12m
Ukuran biasa kami: 29.4x5.6mm, 36.9x7.73mm, 62.9x7.3mm dll
Karakteristik tabung baja bantalan:
Kekuatan tinggi
Tinggi presisi
Kualitas Permukaan yang Baik
Kualitas stabil
Kerontokan yang halus
TORICH Jaminan Kualitas
Proses Produksi:
Pengolahan panas
Tabung Baja Produksi 100Cr6:
ISO 683-17 GCr15 100Cr6 Cold Drawn Seamless Pipe Bearing Tube (Tabung Bantalan Pipa Tanpa Jajar)
